MachineU > China Products > Minerals & Metallurgy > Wire Mesh > Barbed Wire
16*16 Double Strand Barbed Wire Coil For Security Fence , High Tensile
16*16 Double Strand Barbed Wire Coil For Security Fence , High Tensile
16*16 Double Strand Barbed Wire Coil For Security Fence , High Tensile
16*16 Double Strand Barbed Wire Coil For Security Fence , High Tensile
Specifications
Brand Name :
TAIYE
Model Number :
TZ67
Certification :
ISO9001
Place of Origin :
Hebei,China
MOQ :
2 Tons
Price :
To be negotiated
Payment Terms :
L/C, D/A, T/T, Western Union
Supply Ability :
200 Tons Per Week
Delivery Time :
Within 15 days
Packaging Details :
5-25Kg/Coil in bulk or woven bags or on Pallet
Name :
High Tensile Barbed Wire 16*16 Double Strand Barbed Wire For Security Fence
Material :
Low corbon steel wire
Wire diameter :
16*16#
Barb length :
3cm
Barbed space :
5"
Length :
400m/Roll
Description

High Tensile Barbed Wire 16*16 Double Strand Barbed Wire For Security Fence

1. Material: High quality and low carbon steel wire, galvanized or PVC wire.

2. Weaving and characteristics: Twist and weaving

3. Application: Used in protection of grass boundary, railways, highway, etc.
4.General use: galvanized barbed wire is a kind of modern security fencing materials fabricated with high-tensile wire. Galvanized barbed wire can be installed to achieve the result of frightening and stopping to the aggressive perimeter intruders, with piecing and cutting razor blades mounted at the top of the wall, also the special designs making climbing and touching extremely difficult. The wire and strip are galvanized to prevent corrosion.

Galvanized Wire
Kinds Electro galvanized wire
Hot galvanized wire
PVC coated wire
Material low carbon steel wire
Packing 25-50kg/coil
Inner plastic and outer hessian cloth
Gauge Gauge SWG mm BWG mm In Metric System mm
8# 4.06 4.19 4.00
9# 3.66 3.76 -
10# 3.25 3.4 3.50
11# 2.95 3.05 3.00
12# 2.64 2.77 2.80
13# 2.34 2.41 2.50
14# 2.03 2.11 -
15# 1.83 1.83 1.80
16# 1.63 1.65 1.65
17# 1.42 1.47 1.40
18# 1.22 1.25 1.20
19# 1.02 1.07 1.00
20# 0.91 0.89 0.90
21# 0.81 0.813 0.80
22# 0.71 0.711 0.70

Gauge of
Strand and Barb in B.W.G.		 Approximate Length per Kilo in Meter
Barbs Spacing 3" Barbs Spacing 4" Barbs Spacing 5" Barbs Spacing 6"
12 × 12 6.0617 6.7590 7.2700 7.6376
12 × 14 7.3335 7.9051 8.3015 8.5741
12-1/2 × 12-1/2 6.9223 7.7190 8.3022 8.7221
12-1/2 × 14 8.1096 8.814 9.2242 9.5620
13 × 13 7.9808 8.899 9.5721 10.0553
13 × 14 8.8448 9.6899 10.2923 10.7146
13-1/2 × 14 9.6079 10.6134 11.4705 11.8553
14 × 14 10.4569 11.6590 12.5423 13.1752
14-1/2 × 14-1/2 11.9875 13.3671 14.3781 15.1034
15 × 15 13.8927 15.4942 16.6666 17.5070
15-1/2 × 15-1/2 15.3491 17.1144 18.4060 19.3386

Packges of Galvanized Barbed Wire

16*16 Double Strand Barbed Wire Coil For Security Fence , High Tensile

16*16 Double Strand Barbed Wire Coil For Security Fence , High Tensile
