Single Loop Rust Proof Galvanized Razor Wire Black Annealed Outdoor Use
Single Loop Rust Proof Galvanized Razor Wire Black Annealed Outdoor Use
Single Loop Rust Proof Galvanized Razor Wire Black Annealed Outdoor Use
Single Loop Rust Proof Galvanized Razor Wire Black Annealed Outdoor Use
Single Loop Rust Proof Galvanized Razor Wire Black Annealed Outdoor Use
Single Loop Rust Proof Galvanized Razor Wire Black Annealed Outdoor Use
Single Loop Rust Proof Galvanized Razor Wire Black Annealed Outdoor Use
Single Loop Rust Proof Galvanized Razor Wire Black Annealed Outdoor Use
Specifications
Brand Name :
Taiye
Model Number :
R-24
Certification :
ISO9001 ISO140001
Place of Origin :
ANPING CHIINA
MOQ :
1Ton
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
20 tons per day
Delivery Time :
3-7 days
Packaging Details :
Inner waterproof paper with woven bag outside, 50 coils be a bundle.
Material :
Galvanized,iron,stainless steel,PVC Coated
Inner wire Dia :
2.5-2.7mm
Razor Thickness :
0.6±0.05mm
Razor Barb Length :
10-65mm
Razor Barb Spacing :
26-100mm
Razor Barb Width :
13-32mm
Razor Type :
Cross Razor or Single Razor
Manufacturer :
Yes
Price :
To be negotiated
Description

Single loop rust proof galvanized black annealed wire razor barbed wire

1.Common specifications

Specification
Thickness
(mm)
Wire Dia.
(mm)
Barb Length
(mm)
Barb Width
(mm)
Barb spacing
(mm)
BTO-10 0.5±0.05 2.5mm±0.1 10±1 13±1 26±1
BTO-12 0.5±0.05 2.5mm±0.1 12±1 15±1 26±1
BTO-18 0.5±0.05 2.5mm±0.1 18±1 15±1 33±1
BTO-22 0.5±0.05 2.5mm±0.1 22±1 15±1 34±1
BTO-28 0.5±0.05 2.5mm±0.1 28±1 15±1 45±1
BTO-30 0.5±0.05 2.5mm±0.1 30±1 18±1 45±1
CBT-60 0.5±0.05 2.5mm±0.1 60±2 32±1 100±2
CBT-65 0.5±0.05 2.5mm±0.1 65±2 21±1 100±2

Single Loop Rust Proof Galvanized Razor Wire Black Annealed Outdoor Use

Concertina Coil Specification
Coil Diameter 300mm 450mm 730mm 730mm 980mm 980mm 1250mm
(12inch) (18inch) (28inch) (36inch) (36inch) (36inch) (50inch)
Recommended Stretch Length 4m 10m 15-20m 10-12m 10-15m 8m 8m
Coil Diameter When Stretched 260mm 400mm 600mm 620mm 820mm 850mm 1150mm
Spiral Turns Per Coil 33 54/55 54/55 54/55 54/55 54/55 54/55
Clips Per Spiral 3 3 3 5 5 7 9

Outside Dia. No.of Loops Standard Length per Coil Typs Notes
300mm 33 4-5m CBT-60.65 Single coil
450mm 33 7-8m CBT-60.65 Single coil
500mm 56 12-13m CBT-60.65 Single coil
700mm 56 13-14m CBT-60.65 Single coil
960mm 56 14-15m CBT-60.65 Single coil
450mm 56 8-9m BTO-10.12.18.22.28.30 Cross type
500mm 56 9-10m BTO-10.12.18.22.28.30 Cross type
600mm 56 10-11m BTO-10.12.18.22.28.30 Cross type
600mm 56 8-10m BTO-10.12.18.22.28.30 Cross type
700mm 56 10-12m BTO-10.12.18.22.28.30 Cross type
800mm 56 11-13m BTO-10.12.18.22.28.30 Cross type
900mm 56 12-14m BTO-10.12.18.22.28.30 Cross type
960mm 56 13-15m BTO-10.12.18.22.28.30 Cross type
980mm 56 14-16m BTO-10.12.18.22.28.30 Cross type

2.Product introduction

Material: low carbon steel wire, stainless steel wire, iron wire, galvanized steel wire, PVC coated steel wire, PVC coated iron wire in blue, yellow,green and other colors.

Assortment:

Electro Barbed Wire

Hot Dipped Barbed Wire

PVC Barbed Wire

Feature:

Aesthetic appearance and protective excellent performance, performance, easy to install, high safety factor, many tricks, and a good deterrent effect, corrosion resistance, aging resistance, sunshine resistance and weather resistance.

Specifications:

IOWA type, 2 strands, 4 points. Barbs' distance 3-6 inches (Tolerance +- 1/2”)

Crossed razor barbed wire/ single coil razor barbed wire/ straight razor barbed wire/ Razor Wire Mesh Fence

Normal package: 4-15kg per coil (different lengths and outside diameters can be ordered per coil ) Moisturer-proof paper coated and woven bags outside. Some customers need paper carton packaging, 5 coils per carton, weight 25-30kg.

Single Loop Rust Proof Galvanized Razor Wire Black Annealed Outdoor Use
