BTO 22 Concertina Razor Fence Wire 10 - 65mm Bard Length For Residences Fencing
BTO 22 Concertina Razor Fence Wire 10 - 65mm Bard Length For Residences Fencing
BTO 22 Concertina Razor Fence Wire 10 - 65mm Bard Length For Residences Fencing
BTO 22 Concertina Razor Fence Wire 10 - 65mm Bard Length For Residences Fencing
Specifications
Brand Name :
Taiye
Model Number :
TA4
Certification :
ISO9000
Place of Origin :
China
MOQ :
200 Rolls
Payment Terms :
D/A, L/C, T/T, Western Union
Supply Ability :
50 Tons per week
Delivery Time :
Within 15 days or as your need
Packaging Details :
Waterproof Paper inside and woven bags outside
Product name :
BTO 22 Concertina Razor Fence Wire 10 - 65mm Bard Length For Residences Fencing
Wire diameter :
2.5mm
Material :
low carbon steel wire or ss wire
Type :
BTO-22，BTO-11,BTO-30
Sheet Thinkness :
0.5mm
Raozr Width :
15mm
Razor Length :
22mm
Razor Distance :
37mm
Color :
Red,Green or as your request
Weight :
5-25kg/roll
Packing :
waterproof paper inside and woven bags outside
Price :
To be negotiated
Description

BTO 22 Concertina Razor Fence Wire 10 - 65mm Bard Length For Residences Fencing

razor barbed wire is a kind of blocking material, which is composed of blades made of galvanized steel or stainless steel plate with punching a sharp knife flake and a high tension galvanized core wire or stainless steel core wire. with its unique appearence and security, razor barbed wire can achieve excellent protection and screen effect. the mainly material of razor barbed wire are galvanized steel and stainless steel plate.

BTO 22 Concertina Razor Fence Wire 10 - 65mm Bard Length For Residences Fencing
Reference
Number
Thickness
Wire Dia
Barb
Length
Barb
Width
Barb
spacing
BTO-10
0.5±0.05
2.5±0.1
10±1
13±1
25±1
BTO-12
0.5±0.05
2.5±0.1
12±1
15±1
25±1
BTO-18
0.5±0.05
2.5±0.1
18±1
15±1
35±1
BTO-22
0.5±0.05
2.5±0.1
22±1
15±1
36±1
BTO-28
0.5±0.05
2.5
28
15
46±1
BTO-30
0.5±0.05
2.5
30
18
46±1
CBT-65
0.6±0.05
2.5±0.1
65±2
21±1
101±2

1. Materials:galvanized iron wire,PVC coated wire ,stainless steel wire and stainless steel sheet

2. Blade Type:BTO-12 BTO-18 BTO-22 CBT-60 CBT-65

3. Wire Dia.:2.0-2.5mm

4. Bard Length:10-65mm

5. Barb Spacing:26-100mm

6. Classification:straight line razor wire,concertina wire,crossed razor barbed wire,razor wire mesh

7. Process and Features:Galvanized steel plate or stainless steel plate punched into certain forms then attached to the steel wire in sharp angle to form the blades.The products offer beautiful

appearance,economic cost,good frightening result and easy installation.Sharp blades coming in the form of concertina by buckles bring very good result of frightening and stopping to the aggressive

perimeter intruders .

8. Applications:widely used in military field,prisons,detention houses,government buildings and other national security facilities.Also fencing of residences,villa wall and windows,express way,railway,

national border lines,ets.

Outside Diameter
No. of Loops
Standard Length per Coil
Type
Notes
450mm
33
8M
CBT-65
Single coil
500mm
41
10M
CBT-65
Single coil
700mm
41
10M
CBT-65
Single coil
960mm
53
13M
CBT-65
Single coil
500mm
102
16M
BTO-10.15.22
Cross type
600mm
86
14M
BTO-10.15.22
Cross type
700mm
72
12M
BTO-10.15.22
Cross type
800mm
64
10M
BTO-10.15.22
Cross type
960mm
52
9M
BTO-10.15.22
Cross type

BTO 22 Concertina Razor Fence Wire 10 - 65mm Bard Length For Residences Fencing
