BT022 CBT60 CBT65 Galvanized Concertina Razor Wire Cross Razor Or Single Razor
BT022 CBT60 CBT65 Galvanized Concertina Razor Wire Cross Razor Or Single Razor
BT022 CBT60 CBT65 Galvanized Concertina Razor Wire Cross Razor Or Single Razor
BT022 CBT60 CBT65 Galvanized Concertina Razor Wire Cross Razor Or Single Razor
BT022 CBT60 CBT65 Galvanized Concertina Razor Wire Cross Razor Or Single Razor
BT022 CBT60 CBT65 Galvanized Concertina Razor Wire Cross Razor Or Single Razor
Specifications
Brand Name :
Taiye
Model Number :
R-06
Certification :
ISO9001 ISO140001
Place of Origin :
ANPING CHIINA
MOQ :
1Ton
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
20 tons per day
Delivery Time :
3-7 days
Packaging Details :
Inner waterproof paper with woven bag outside, 50 coils be a bundle.
Material :
Galvanized,iron,stainless steel,PVC Coated
Inner wire Dia :
2.5-2.7mm
Razor Thickness :
0.6±0.05mm
Razor Barb Length :
10-65mm
Razor Barb Spacing :
26-100mm
Razor Barb Width :
13-32mm
Razor Type :
Cross Razor or Single Razor
Price :
To be negotiated
Description

BT022 CBT60 CBT65 Galvanized Concertina Razor Wire Price

1.Product introduction

Razor barbed wire is also named concertina coils or razor type barbed wire.It is a new type of guard fence.


Characteristics: With beautiful and sharp blades and strong core wire,razor wire has the features of good deterrent effects,nice appearance,easy installation,economical and practical and other properties.


Application: Razor barbed wire is widely used in apartment house,organization units,prisons,frontier fence,military fields and other sites requiring severe fencing and security.


Classification: Razor wire can be classified into concertina coils,straight type razor wire,crossed type and flat type according to the installation models.

2.Common specifications

Specification
Thickness
(mm)
Wire Dia.
(mm)
Barb Length
(mm)
Barb Width
(mm)
Barb spacing
(mm)
BTO-10 0.45±0.05 2.0-3.0 10±1 13±1 26±1
BTO-12 0.45±0.05 2.0-3.0 12±1 15±1 26±1
BTO-18 0.45±0.05 2.0-3.0 18±1 15±1 33±1
BTO-22 0.45±0.05 2.0-3.0 22±1 15±1 34±1
BTO-28 0.45±0.05 2.0-3.0 28±1 15±1 45±1
BTO-30 0.45±0.05 2.0-3.0 30±1 18±1 45±1
CBT-60 0.45±0.05 2.0-3.0 60±2 32±1 100±2
CBT-65 0.45±0.05 2.0-3.0 65±2 21±1 100±2

Concertina Coil Specification
Coil Diameter 300mm 450mm 730mm 730mm 980mm 980mm 1250mm
(12inch) (18inch) (28inch) (36inch) (36inch) (36inch) (50inch)
Recommended Stretch Length 4m 10m 15-20m 10-12m 10-15m 8m 8m
Coil Diameter When Stretched 260mm 400mm 600mm 620mm 820mm 850mm 1150mm
Spiral Turns Per Coil 33 54/55 54/55 54/55 54/55 54/55 54/55
Clips Per Spiral 3 3 3 5 5 7 9

Outside Dia. No.of Loops Standard Length per Coil Typs Notes
300mm 33 4-5m CBT-60.65 Single coil
450mm 33 7-8m CBT-60.65 Single coil
500mm 56 12-13m CBT-60.65 Single coil
700mm 56 13-14m CBT-60.65 Single coil
960mm 56 14-15m CBT-60.65 Single coil
450mm 56 8-9m(3 clips) BTO-10.12.18.22.28.30 Cross type
500mm 56 9-10m(3 clips) BTO-10.12.18.22.28.30 Cross type
600mm 56 10-11m(3 clips) BTO-10.12.18.22.28.30 Cross type
600mm 56 8-10m(5 clips) BTO-10.12.18.22.28.30 Cross type
700mm 56 10-12(5 clips) BTO-10.12.18.22.28.30 Cross type
800mm 56 11-13m(5 clips) BTO-10.12.18.22.28.30 Cross type
900mm 56 12-14m(5 clips) BTO-10.12.18.22.28.30 Cross type
960mm 56 13-15m(5 clips) BTO-10.12.18.22.28.30 Cross type
980mm 56 14-16m(5 clips) BTO-10.12.18.22.28.30 Cross type

3.Galvanized razor wire

BT022 CBT60 CBT65 Galvanized Concertina Razor Wire Cross Razor Or Single Razor

PVC Coated

BT022 CBT60 CBT65 Galvanized Concertina Razor Wire Cross Razor Or Single Razor

4.Package

waterproof paper inner, woven bag outside or with carton for Low price concertina hot dipped galvanized razor barbed wire

5.Application

BT022 CBT60 CBT65 Galvanized Concertina Razor Wire Cross Razor Or Single Razor
