IP65 Rugged RFID Fixed Reader with Reliable Sealing Performance and Long Service Life
IP65 Rugged RFID Fixed Reader with Reliable Sealing Performance and Long Service Life
IP65 Rugged RFID Fixed Reader with Reliable Sealing Performance and Long Service Life
IP65 Rugged RFID Fixed Reader with Reliable Sealing Performance and Long Service Life
IP65 Rugged RFID Fixed Reader with Reliable Sealing Performance and Long Service Life
IP65 Rugged RFID Fixed Reader with Reliable Sealing Performance and Long Service Life
IP65 Rugged RFID Fixed Reader with Reliable Sealing Performance and Long Service Life
IP65 Rugged RFID Fixed Reader with Reliable Sealing Performance and Long Service Life
IP65 Rugged RFID Fixed Reader with Reliable Sealing Performance and Long Service Life
IP65 Rugged RFID Fixed Reader with Reliable Sealing Performance and Long Service Life
Specifications
Brand Name :
SCANMAX
Model Number :
RD-AF26
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 PCS/ week
Delivery Time :
within 5 working days after receiving the balance
Packaging Details :
Normal craft paper and foam
Size :
431mm×431mm×60mm
Weight :
3.3Kg (excluding mount bracket)
Material :
engineering plastic ASA, aluminum alloy
Working frequency :
902MHz～928MHz
Polarization :
linear
Working Temperature :
-40℃～+70℃
Description

RFID Fixed Reader can convert electromagnetic wave into current signal or convert current signal into electromagnetic wave. It is an essential part of RFID system. It transmits frequency signal between tags and reader. Connecting with reader directly through coax, it can read or write RFID tag data efficiently. With advantages of rugged structure, high IP grade, reliable sealing performance and long service life, it can be widely used in vehicle management, livestock management, warehouse management RFID system.

Working frequency: 902～928MHz
quad pole antenna
Polarization: linear
High gain: ＞12dBi
Standing wave ratio: ≤1.5:1
Excellent anti-vibration and shock resistance performance
IP65
Beautiful appearance and rugged material
Easy installation and maintenance

Parameters :
Size: 431mm×431mm×60mm
Weight: 3.3Kg (excluding mount bracket)
Material: engineering plastic ASA, aluminum alloy
Connector type: N-type RF coaxial connector

Performance :
Working frequency: 902MHz～928MHz
Voltage standing wave ratio: ≤1.5:1
Gain: ＞12dBi
H plane HPBW: 45°
E plane HPBW: 45°


Polarization: linear
Antenna Impedance: 50Ω

Environmental parameter :
Working Temperature: -40℃～+70℃
Storage Temperature: -40℃～+70℃
Working Humidity: 5%RH～95%RH
