Customized Micro QR Code POS Card Engine Card Payment Machine
Customized Micro QR Code POS Card Engine Card Payment Machine
Customized Micro QR Code POS Card Engine Card Payment Machine
Customized Micro QR Code POS Card Engine Card Payment Machine
Customized Micro QR Code POS Card Engine Card Payment Machine
Customized Micro QR Code POS Card Engine Card Payment Machine
Customized Micro QR Code POS Card Engine Card Payment Machine
Customized Micro QR Code POS Card Engine Card Payment Machine
Specifications
Brand Name :
HST
Certification :
Rohs，Aiming (red laser) :EN/IEC 60825-1:2007 (class 2)
Place of Origin :
China
MOQ :
1PC
Price :
1usd
Payment Terms :
L/C, T/T
Supply Ability :
10,000 pcs/day
Delivery Time :
7-10 days
Packaging Details :
Carton
Dimension :
23.4x16.5x.8
Weight :
2.6g
Operation Voltage :
VCC 3.0-3.6V, VCC_IO 3.0-3.6V
Operation Current :
108mA（max)
Standby Current :
65mA(max)
Fall Test :
Withstand 1.2m drop to cement floor(50 times repeated) 1.2meters
Description

Micro QR Code POS Engine Reader Easy Use & Function Customized

Description:

The Micro QR Code POS Engine Reader offers ease of use and customizable functionalities, providing users with a convenient and efficient payment solution.

This solution features a Micro QR Code POS Engine Reader, known for its user-friendly design. Users simply need to place the Micro QR Code above the reader to quickly read the QR code information. The reader provides an intuitive interface and simple operational flow, enabling users to effortlessly complete the payment process.

Furthermore, this solution offers customization options. Merchants can customize the POS engine according to their specific needs. For example, they can customize the interface layout, add specific function buttons, or adjust the payment flow to cater to different business requirements. This customization capability allows the solution to better meet the individual needs of merchants and provide a more personalized payment experience.

The combination of ease of use and customization features in the Micro QR Code POS Engine Reader makes it a convenient and efficient payment solution. Users can complete payments through simple operations, while merchants can customize the solution to provide a better service experience according to their specific requirements.

Specification:

Parameter Performance
Image sensor Mono CMOS
Pixel 1280(H)× 800(V)
Shutter Global shutter
Frame rate Up to 60fps
Illumination White light
Aiming Red laser
Field of view Horizontal 39.5°,Vertical 26.1°
Decode type

2D

Aztec Code,Han Xin Code,Data Matrix,Maxi Code,Micro QR Code,QR Code, etc
1D Standard one-dimensional code
Postal Code Australian Post,British Post,China Post,Japanese Post,KIX Post,Korea Post,Planet Code,Postnet,Royal Mail Code (RM4SCC), etc

DOF*

 EAN-13(13mil) 45~590mm
Code 39(20mil) 45~930mm
Code 39(10mil) 65~470mm
Code 39(5.5mil) 70~340mm
Code 39(3.9mil) 60~220mm
Data Matrix(15mil) 50~420mm
Data Matrix(10mil) 50~300mm
Resolution* 1D:2.5mil,Data Matrix:5mil,PDF417:3mil
Contrast* ≥20%

Angle **

 pitch ±60°
tilt ±180°
skew ±60°

Details:

Customized Micro QR Code POS Card Engine Card Payment Machine

Customized Micro QR Code POS Card Engine Card Payment Machine
