SS630 Stainless Steel Slot Die Film Applicator 1μM Micrometer Accuracy
SS630 Stainless Steel Slot Die Film Applicator 1μM Micrometer Accuracy
Specifications
Brand Name :
TICO
Model Number :
STC-TMQ-S100
Certification :
CE
Place of Origin :
Shenzhen, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
120 sets per month
Delivery Time :
3~5 days
Packaging Details :
Standard export wooden box package
Material :
SS 630 stainless steel
Coating thickness :
Max. 5mm
Micrometer accuracy :
1μm
Dimension :
L170 * W90 * H110mm
Weight :
2kg
Description

SS630 Stainless Steel Slot Die Film Applicator 1μM Micrometer Accuracy

Slot Die Film Applicator

Product Introduction of Slot Die Film Applicator

It is used for film coating on sheet-type substrate surface. It is compatible with slot extrusion coating and doctor blade coating. It can be used for a wide range of film coating research, such as battery material film, OLED, solar photoelectric film &polymer conductive film, etc.

Product Specifications

Model STC-TMQ-S100
Material SS 630 stainless steel
Coating way Slot die coating Blade coating
Accuracy Lip straightness≤4μm Straightness≤4μm
Die chamber volume 2.6ml /
Coating width Max. 100mm, “C” type opening, customized size is available 150mm
Micrometer accuracy 1μm 1μm
Coating thickness 5mm 5mm
Dimension L170 * W90 * H110mm
Weight 2kg

Key Features

(1) It is compatible with slot extrusion coating and doctor blade coating. (Battery slurry feeding device is required for slot die film coating)

(2) Wide application range, high coating accuracy.

(3) The coating is sealed during extrusion coating, which is less affected by environment.

(4) It adopts anti-corrosion material, long lifetime.

(5) Smaller size, operation conveniently.

SHENZHEN TICO TECHNOLOGY CO., LTD

1. Total solution for Lithium-ion Battery R&D.

2. One-stop service in designing, manufacturing and marketing of battery equipment &material.

3. An integrated company of industry &trade.

FAQ

1. Are you a manufacturer?

TICO: Yes, our factory is located in Shenzhen, China.

We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.

2. Do you accept customized product?

TICO: Yes, most of our products can be customized to meet different requirements.

3. Will you provide test video before dispatch?

TICO: Yes, we take test video for every equipment before dispatch, which will display how to use it.

4. Can you offer overseas installation service?

TICO: Yes, we can dispatch professional engineer for on-site installation service.
