High Current Ant 8s To 32s 100a 200a 300a LTO Battery BMS Li Ion Lifepo4 LTO Smart Bms With BT

Product introduction:
Charging current: 50A
Banlance current: 100MA
Wiring method: same port
Size: length 19CM width 7CM thickness 2.5CM
Single cell voltage: detection range 1V-4.6V, accuracy less than 5Mv
Overcharged and paid: protected
Short circuit protection: short circuit protection current can be set
BT connection: for Android
Applicable battery:
8S to -32S version :
8-32S Li-ion Battery; 8-32S Lifepo4 Battery;10-32S Titanium LTO lithium
Coulomb counter: accurate calculation based on current versus time
Battery remaining capacity, error range is less than 5%
Power consumption: 3MA at work
1.5MA during standby

Note: The cable is connected from the first black wire on the far right to the total negative electrode of the battery pack, which
is the negative electrode of the first cell of batteries.

Then start from the black wire and start from the first white wire from right to left to the first cell, second cell, third cell
of the battery and so on, and connect to the positive electrode of each cell in sequence. The minimum number of cells to be
connected is 8S, and the batteries of less than 32S are not left empty. After connecting, use a multi-meter to measure the voltage
on the plug row. There is no problem to confirm that the voltage is correct before plugging into the protection board The same
wire is connected to a red wire, regardless of its color), note that the last red wire on the third and last socket is B + which
supplies power to the protection board. It is connected to the cable of the last cell of batteries. That is to say, two wires need
to be connected to the bms on the last positive pole of the battery. There is a hole behind the last red wire of the third socket
and B + is redundant. You can leave it alone. Other instructions are the same as the 24S protection board

RFQ

1.What is the common port and separate port? what is the difference?
We take 13S 48V 15A BMS as an example, common port 15A means your charge cathode and discharge cathode are connected in the same point end(our P-), charge cathode and discharge cathode are used in the common connection
port, so the charge current and discharge current are the same 15A. while the separate port is separately connected by charge cathode (C-) and discharge cathode (P-), so the charge current and discharge current are different, discharge current 15A, charge current 8A.

2.What is the balance function?
The working principle and function are as followings, when your one cell voltage is upto alarm voltage(Li-ion upto 4.18V, LifePo4 upto (3.6V), then the cell Balance starts to work, balance resistance starts discharge with 35ma(when balance discharge starts to work, BMS will starts a little heat up, which is the normal reflection), the cell is in both charging and discharging status, and others which are not reached to alarm voltage(Li-ion 4.18V, LifePo4 3.6V)are only in charging status, no discharging, when the fast cell voltage is reached to alarm voltage (Li-ion 4.25V, LifePo4 3.75V) BMS starts off power protection, all the other cells are all in stop of charging, this process will enable your battery charging in balance current, and your battery voltage are in balance status, but when your cell voltage difference are in a big range, then balance can not be functionning well

3.The relationship between Battery capacity and BMS current?
There is no direct relationship between Battery capacity and BMS current, big capacity doesn`t mean a big battery, but rely on continue current, that is to say if your engine is powerful, your should choose high current of BMS, it is not relied on battery capacity.

4. What type of charger should I choose?
Lithium battery must choose specific charger, do not use Charger for Leadacid battery, for leadacid charger may have MOS with high pressure breakdown protection, which will not protect of BMS over charge. Life Po4 battery charger voltage=battery string No.X3.6V, while Li-ion battery charger voltage=Battery string No.X4.2V.

5. What current BMS should I choose ?
Take 10S 36V as an example: what current BMS you choose is relied on your E-bicycle Motor power and current limitation of controller. eg., choose 15A for below 350W, 20A for below 500W, 30A for below 800W, 60A for Below 1000W, higher than 1200W are contact with our service specialist for suggestions, one inall, continue current shall be higher than current limitation in Controller.

6. Whether my BMS damaged?
if you want to judge if the BMS is damaged, please take the folowing steps, to test if each cell voltage is the same with
voltmeter? if the cell voltage difference is over 1.0V, the fault is displayed that it cannot run far, no power supply at the
start range, short charge time, all these issues are almost caused by battery cells, if BMS damaged is displyed as no charge, no discharge, no discharge while the battery has voltage.
