Grade A 230AH 3.2 V Lifepo4 Battery For Electric Power Systems
Grade A 230AH 3.2 V Lifepo4 Battery For Electric Power Systems
Grade A 230AH 3.2 V Lifepo4 Battery For Electric Power Systems
Grade A 230AH 3.2 V Lifepo4 Battery For Electric Power Systems
Grade A 230AH 3.2 V Lifepo4 Battery For Electric Power Systems
Grade A 230AH 3.2 V Lifepo4 Battery For Electric Power Systems
Specifications
Brand Name :
XUWEN
Model Number :
230AH LiFePO4 Battery Packs
Certification :
CE/RoHS/UN38.3/MSDS/BIS
Place of Origin :
China
MOQ :
10pcs
Price :
To be negotiated
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100000pcs/month
Delivery Time :
To be negotiated
Packaging Details :
Packed in export carton Box
Cycle life: :
4000 Cycles
Normal Voltage: :
3.2V
Max charge voltage: :
3.65v
Battery Size: :
204.6*173.93*53.85mm
Max discharge current: :
230Ah
Function: :
Lifepo4 pack
Description

Grade A 230AH LiFePO4 Battery Packs Matched Batched 3.2V EV LF230 Lifepo4 Pack 230Ah Lithium Battery

Item
Data information
Model
230AH 3.2V LiFePO4 Battery Cell
Real Capacity
About 240Ah
Nominal Voltage
3.2v
Max Discharge Current
1C/ 230A
Max Charge Voltage
3.65v
AC Impedance Resistance
≤0.25mΩ
Charging Temperature
-5-60℃
Discharging Temperature
-30-60℃
Cycle Life
≥ 4000 times
Weight
4.11kg
Dimensions (L*W*H)
204.6*173.93*53.85mm
Applications
Electric Power Systems,Home Applicances,Electric vehicles,Golf carts,electric scooter,electric bicycle,used cars and so on.

Grade A 230AH 3.2 V Lifepo4 Battery For Electric Power Systems

FAQ

1,Q: What's the main product in XUWEN?
A: Rechargeable battery: Li-ion, Lipo battery and power battery pack.
2,Q: What is overcharge?
A: After charge, tested the batteries' initial state and capacity. Charge to 10.0V at 3C current, then charge to 0.01C at CV mode.
Observe changes in battery appearance.
3,Q: What is over discharge?
A: After charge, test the batteries' initial state. When the batteries are normal, discharge to 0V at 0.5C. Observe changes in
battery appearance.
4. Q: Can I have a sample order?
A: Yes, we accept sample order to test and check quality. Batteries can be made as require.
5. Q: Do you have MOQ limit?
A: Yes, we have MOQ limit for mass production, but it depends on battery model. Please contact us for details.
6. Q: How about the lead time?
A: Samples will takes 5-7 business days. Mass production will takes 25-30 days. It depends on quantity.
7. Q: How about shipping and delivery time?
A: Generally, battery will be shipped via Express, such as DHL, TNT, FedEx and UPS, delivery time is 3-5 business days. Or DDP
service, delivery time is 11-15 business days. Airline and sea shipping also available.
8. Q: What about after-sale service?
A: We will offer you 1 year guarantee. If there are any problems, please inform us, we will offer you positive solutions.
