Husbandry Equipment Poultry Battery Cage Layer Chicken Animal A Type Q235
Husbandry Equipment Poultry Battery Cage Layer Chicken Animal A Type Q235
Husbandry Equipment Poultry Battery Cage Layer Chicken Animal A Type Q235
Husbandry Equipment Poultry Battery Cage Layer Chicken Animal A Type Q235
Specifications
Brand Name :
Silverstar
Model Number :
A3L90,A3L96,A3L120,A4L120,A4L160
Certification :
SGS, ISO9001, CE, SONCAP
Place of Origin :
China
MOQ :
30 Set
Price :
$140/ Set
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000 Set / Week
Delivery Time :
15-30 days
Packaging Details :
FCL: Standard Export Sea Worthy Packaging LCL: Wooden Case Package
Product Name :
A Type Battery Layer Chicken Cage Animal Cage
Material :
Q235A Hot Dipped Galvanized Steel Wire Mesh
Type :
A Type Layer Chicken Cage
Tiers :
3, 4, 5 Tiers
Capacity :
90 to 160 birds/ Set
Cage Size :
195*230*150cm, 215*230*200cm
Conditon :
New
Warranty :
1 Year
Description

Poultry Husbandry Equipment A Type Battery Layer Chicken Cage Animal Cage

Product Description

1.A type battery layer cage

2. 3tiers, 4tiers,5 tiers

3:Q235 double hot galvanized anti-corrosion

4:Q235 national standard double hot galvanized bridge steel cage,hot galvanized steel feed trough,ball type automatic water equipment ,white PVC pipe ,3MM U type galvanized steel shelves,closed-end pressure-reducer;Al-Zn material feeding system,AL-Zn material manure cleaning system,ventilation system,lighting system,environment controlling system and so on.

A Type Layer Chicken Cage Including

1: Cage with drinking system (Basic configuration, manual)

2: Automatic feeding system (Not mandatory option)

3: Automatic drinking system (Not mandatory option)

4: Automatic manure cleaning system (we have two types, Belt type and scraper type ) (Not mandatory option)

5: Automatic ventilation cooling system (Close house need it, Open house don't need it)

A Type Layer Chicken Cage Size

A Type 3 Tiers Layer Cage
Model Capacity Cage Size Cell Size Cell Capacity Door Qty/20ft container
1 90birds 195x230x150cm 39x38x38cm 3birds/cell 5doors 110sets
2 96birds 195x230x150cm 48.7x38x38cm 4birds/cell 4doors 110sets
3 96birds 172x230x160cm 43x41x41cm 4birds/cell 4doors 105sets
4 120 birds 195x230x160cm 39x41x41cm 4birds/cell 5doors 105sets
5 120 birds 195x236x160cm 39x45x41cm 4birds/cell 5cells 85sets
6 120birds 215x230x160cm 43x41x41cm 4birds/cell 5cells 100sets
A Type 4 Tiers Layer Cage
Model Capacity Cage Size Cell Size Cell Capacity Door Qty/20ft container
1 120birds 195x230x190cm 39x38x38cm 3birds/cell 5doors 80sets
2 128birds 195x230x190cm 48.7x38x38cm 4birds/cell 4doors 80sets
3 128birds 172x230x200cm 43x41x41cm 4birds/cell 4doors 78sets
4 160 birds 195x230x200cm 39x41x41cm 4birds/cell 5doors 78sets
5 160 birds 195x236x200cm 39x45x41cm 4birds/cell 5cells 65sets
6 160birds 215x230x200cm 43x41x41cm 4birds/cell 5cells 75sets

Advantage

1. 3-10 tiers battery cage: Reasonable high-density raising meets different needs. Reduced energy costs for heating or cooling.

2. Q235 High Quality Steel Material from Brand

Manufacturers: 275g/m² Hot-dip galvanized steel.Stronger equipment and 20 years service life.
Numerical Control Process Technology: High precision, easy to install,operate smoothly.

3. 2.15mm High Quality Steel Mesh : Bear high weight with long-lasting better elasticity.
Two Reinforcing Ribs at Each Bottom Mesh: 50kg/㎡ Load-bearing Bottom Mesh.

4. Reasonable Distance in Cages: Small temperature difference inside and outside the cage.
Two Lines Stainless Steel Nipple Pipe: The water supply is safe and adequate.
450cm²/bird: Happy chickens lay more eggs.

5. Bottom Mesh with 8 ° Slope: The egg rolls down gently.
PVC Egg Baffle: Prevent chicken peck eggs.
Top Mesh: Prevent the birds peck manure and scurry.
Sliding Grids: Easy to move birds, no chicken escape.

6. Deep ‘V’ Feed Trough with Inner Rim:

Saving feed cost.
Automatic Feeding System:

Every chicken has adequate feed intake

Husbandry Equipment Poultry Battery Cage Layer Chicken Animal A Type Q235
