100V Voltage Battery Charge Discharge Tester
100V Voltage Battery Charge Discharge Tester
Specifications
Brand Name :
BT
Model Number :
BT-100V10C20F
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
USD 5600-7000 Set
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
30 set month
Delivery Time :
15 work days
Packaging Details :
Wooden case
Product name :
battery pack aging machine
Function :
battery charge and discharge
Voltage :
max 100V
Charge :
10v
Discharge :
20v
Power :
AC 380V ±10% / 50Hz
Case size :
450*300*170MM
Cabinet size :
900*600*190MM
Database :
Using SQL database to manage test data
Warranty :
2 Years
Description

100V 10A charging 20A discharging current

battery pack aging machine

Power

AC 380V ±10% / 50Hz

voltage

Measuring range

10~100V

Accuracy

±(0.2% of reading + 0.2% of range)

Electric Current

Charging range

0~10A

Charging accuracy

±(0.2% of reading + 0.2% of range)

Discharge range

0~20A

Accuracy

±(0.2% of reading + 0.2% of range)

Charging

Constant voltage cut-off current

Lowest 10mA

Capacity

Accuracy

±1‰

Power

Discharge power

Less than or equal to 2000W

Time

Inspection time

Receive real time <2S

Timing range

0~999 H/ step

Data recording interval

≥5S

Median version

1.1 Series

Charging

Charging mode

Constant current and constant voltage charging

Cut-off condition

Voltage, current, relative time, overcharge protection

Discharge

Discharge mode

Constant current discharge

Cut-off condition

Voltage, relative time, over-discharge protection

Circulates

Cyclic range

1 ~ 999 times

Single cycle number of steps

100

Voltage and current detection sampling

Four wire connection

Noise

<50dB

Database

Using My SQL database to manage test data

Communication Mode of upper computer

Based on TCP / Ip Protocol, serial port

Data output mode

EXCEL,TXT,Chart

Communication interface

Mesh opening

Number of channels per cabinet

12

Case size

W*D*H:450MM*300MM*170MM

Cabinet size

W*D*H:900MM*600MM*190MM

Advantage:

1. In network mode, online automatically, no manual connection is required.

2. Use Mysql database to save data, to ensure that data will not be lost, provide measurement data

back-check function.

3. A small number of instruments, you can communicate with PC software through serial port.

4. Many instruments can use network to communicate with PC software, reduce the computer interface,

only one interface, you can control all instruments, to ensure the real-time and integrity of communication data.

5. The instrument provides P + and P-interfaces, as well as CH + and CH-, which can measure special finished

batteries and charge and discharge on an instrument.

100V Voltage Battery Charge Discharge Tester100V Voltage Battery Charge Discharge Tester100V Voltage Battery Charge Discharge Tester

FAQ

A:How long is the guarantee period of the machine?

B:Our machines are guaranteed for two years, during which the company will repair them free of charge if there is any problem.

A:Do you support after sales service?

B:Yes, after purchase we will have professionals to install and train, and the warranty is two years. Exported to

Europe and the United States, Southeast Asian countries, there is a site in India

A:What scope does the product apply to?

B:Company 12 years committed to column Battery Pack Automation Production Equipment, and column Battery

Pack Automation Production Line. Products are mainly used in digital batteries, energy storage batteries, tool

batteries, power batteries, automotive batteries, etc.
