In modern manufacturing industry, trackless flat car has become one of the important logistics equipment. Especially in the mold factory, the application of trackless flat car is increasingly popular.
The application of trackless flat car in mold factory
Trackless flat car is widely used in mold factory. They are commonly used to move molds from one workstation to another. In the mold manufacturing process, the mold needs to pass through multiple workstations, each of which needs to perform different operations. By using trackless electric flatcars, molds can be easily moved from one workstation to another, thus increasing production efficiency.
The advantages of Trackless flat car
1. Can turn
Trackless flat car can be turned by steering wheels without the need for external equipment. This makes the trackless flat car more flexible to move in a small space.
2. Heavy Duty
Trackless electric flatcars can withstand heavy loads, which makes them very useful when transporting heavy items. In the mold manufacturing process, molds are usually very heavy, so it is necessary to use trackless flat car that can withstand heavy loads.
3. Low noise
Trackless electric flat cars usually use batteries as their power source, so they are very quiet. This makes them very useful for use in environments that need to be kept quiet.
4. Safe
Trackless flat car can improve safety by adding safety equipment. For example, sensors can be added to detect obstacles and stop movement when they are detected.
The application case of trackless flat car in mold factory
In some mold factories, trackless flat car has become one of the main logistics equipment. For example, a mold factory uses trackless flat car to move molds from injection molding machines to cooling machines and from cooling machines to inspection stations. The use of trackless flat car to move molds from one workstation to another is very efficient and can improve production efficiency.
In addition, a mold factory uses a trackless flat car to move the mold from the warehouse to the workstation, and then move the mold from the workstation back to the warehouse. This way of use can reduce the time and cost of manual handling of molds and improve logistics efficiency.
The application of trackless flat car in mold factory has become a trend. They have advantages such as turn-ability, heavy duty, low noise, safety, automation, etc., which make them very useful in the mold making process. By using trackless electric flatcars, molds can be easily moved from one workstation to another, thus increasing production efficiency. Therefore, the trackless flat car in the mold factory application prospect is very broad.
Model | BWP-2T | BWP-5T | BWP-10T | BWP-15T | BWP-20T | BWP-25T | BWP-30T | BWP-40T | BWP-50T | BWP-60T | BWP-70T | BWP-80T | BWP-100 | |
Rated load(t) | 2 | 5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | 60 | 70 | 80 | 100 | |
Table Size | Length(L) | 2000 | 2200 | 2300 | 2400 | 2400 | 3500 | 3500 | 5000 | 5500 | 5600 | 6000 | 6500 | 6600 |
Width(W) | 1500 | 2000 | 2000 | 2100 | 2200 | 2200 | 2200 | 2500 | 2600 | 2500 | 2600 | 2800 | 3000 | |
Heigth(H) | 450 | 500 | 550 | 600 | 600 | 700 | 700 | 800 | 800 | 850 | 900 | 950 | 1200 | |
Wheel Base(mm) | 1080 | 1650 | 1650 | 1600 | 1650 | 1650 | 1650 | 2000 | 2000 | 1800 | 1850 | 1950 | 2000 | |
Axle Base(mm) | 1380 | 1680 | 1700 | 1830 | 1850 | 2700 | 2700 | 3600 | 2850 | 2900 | 3500 | 3500 | 4000 | |
Wheel Dia.(mm) | Φ250 | Φ300 | Φ350 | Φ400 | Φ400 | Φ450 | Φ450 | Φ500 | Φ600 | Φ600 | Φ600 | Φ600 | Φ600 | |
Wheel Quantity(pcs) | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 6 | 6 | 8 | |
Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
Running Speed(mm) | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
Motor Power(kw) | 2*1.2 | 2*1.5 | 2*2.2 | 2*3.5 | 2*4.5 | 2*5.5 | 2*5.5 | 2*6.3 | 2*7.5 | 2*10 | 2*12 | 30 | 40 | |
Batter Capacity(Ah) | 250 | 180 | 250 | 330 | 400 | 400 | 450 | 440 | 500 | 600 | 600 | 800 | 1000 | |
Battery Voltage(V) | 24 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | 72 | 72 | 72 | |
Running Time When Full Load | 2.5 | 2.88 | 2.8 | 2.3 | 2.2 | 1.8 | 2 | 2.6 | 2.5 | 2.2 | 1.8 | 2 | 1.9 | |
Running Distance for One Charge(Km) | 3 | 3.5 | 3.4 | 2.8 | 2.7 | 2.2 | 2.4 | 3.2 | 3 | 2.7 | 2.2 | 2.4 | 2.3 | |
Max Wheel load(KN) | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 152 | 185 | 190 | |
Reference Wight(t) | 2.3 | 3.6 | 4.2 | 5.5 | 5.9 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | 12.8 | 14.6 | 26.8 |
