Specifications
Place of Origin :
Xinxiang
Brand Name :
BEFANBY
Model Number :
KPJ-15T
Certification :
CE,SGS,ISO9001
Price :
Negotiation
Packaging Details :
Electrical parts will add shields. As required by the customer, we can add a fixed packing.
Delivery Time :
50-60 days as usual delivery,40-50days for urgent delivery
Payment Terms :
30% deposit by T/T in advance, 70%balance by T/T before dispatch
Supply Ability :
600 sets one year
MOQ :
1 set
Shipment port :
Qingdao, Tianjin, Shanghai
Product name :
Cable drum powered rail transfer equipment
Load capacity :
1-300t
Dimension(mm) :
Customized
Exported countries :
Singapore, Australia, South Africa, Mexico
Running speed(m/min) :
0-25
Rail gauge(mm) :
1435
Rail type :
P24
Power source :
Cable drum
Colour :
Customized
Description

30t Cable drum powered rail transfer equipment industry apply


This kind of rail transfer equipment is powered through cable drum, the cable drum is installed at the bottom of the cart. It has no limit on working frequency and rail instruction.

Description

1. 16T Capacity trasfer vehicleis steel plate welding.
2. travelling vehicle steel structure is box beam structure.
3. travelling vehicle is powered by retracting and releasing cable on cable reel
4. Low cost and convenient use
5. Heavy load capacity
Main Parts cart frame, wheels, AC motor, speed reducer, cable drum, cable arranger, electrical control box,hand-held pendant, remote controller, alarm light
Advantages

1. Can be used frequently
2. Simple structure, low cost and not so strict requirement on rails construction
3. This series' travelling vehicle can also be used in high temperature environment.
Application

1. 16T Capacity travelling vehicle is more often used to transfer materials for a short distance from one workshop to another.
2. It can be used in the high-temperature environment and other worse condition with the strong bearing ability.


Parts achievements

Singapore Cable power transfer car KPJ-15T 1 SET
Australia Battery power transfer car KPX-60T 1 SET
South Africa Battery power transfer car KPX-6T 2 SET
Mexico cable drum powered transfer car KPJ-60T 1 SET




Technical parameter

Model KPJ-15T
Rated Load(t) 15
Table size(mm) 4500*2200*600
Wheel Base(mm) 2800
Rail Gauge(mm) 1435
Wheel Diameter(mm) 350
Wheel Quantity(Pcs) 4
Ground Clearance(mm) 50
Running Speed(m/min) 20
Motor Power(Kw) 2.2
Running Distance(m) 25
Max Wheel Load(KN) 64.5
Reference Weight(t) 5.2
Recommended Rail Model P24




This kind of transfer equipment is widely applied in steel factory, production line, warehouse, shipyard etc, to transfer heavy material from one location to another.

The V-frame, hydraulic lifting device can be added on the platform if needed. Beside stright rails, the rail transfer equipment also can be run on turning rails, arc-shaped rails.



Need further information, pls contact us.
