Kpd-60 Tons Motorized / Electric Transfer Trolley For Working Line 0-20m/Min Speed
Kpd-60 Tons Motorized / Electric Transfer Trolley For Working Line 0-20m/Min Speed
Kpd-60 Tons Motorized / Electric Transfer Trolley For Working Line 0-20m/Min Speed
Kpd-60 Tons Motorized / Electric Transfer Trolley For Working Line 0-20m/Min Speed
Kpd-60 Tons Motorized / Electric Transfer Trolley For Working Line 0-20m/Min Speed
Kpd-60 Tons Motorized / Electric Transfer Trolley For Working Line 0-20m/Min Speed
Kpd-60 Tons Motorized / Electric Transfer Trolley For Working Line 0-20m/Min Speed
Kpd-60 Tons Motorized / Electric Transfer Trolley For Working Line 0-20m/Min Speed
Kpd-60 Tons Motorized / Electric Transfer Trolley For Working Line 0-20m/Min Speed
Kpd-60 Tons Motorized / Electric Transfer Trolley For Working Line 0-20m/Min Speed
Kpd-60 Tons Motorized / Electric Transfer Trolley For Working Line 0-20m/Min Speed
Kpd-60 Tons Motorized / Electric Transfer Trolley For Working Line 0-20m/Min Speed
Specifications
Brand Name :
BEFANBY
Model Number :
KPD
Certification :
CE,SGS,ISO9001
Place of Origin :
Henan, China
MOQ :
1 set/sets
Price :
$4000-$6000/ per set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 set/sets per year
Delivery Time :
40-50 days as usual delivery,30-40days for urgent delivery
Packaging Details :
The transfer trolley will be packed by the tarp, the parts will be shipped in the high quality wooden case.
Material :
Q235
Running speed :
0-20m/min
Running distance :
According to customers'demand
Warranty :
12 months
load capacity :
1-500T
Application :
Industrial field
Port :
Qingdao/Tianjin/Shanghai
Color :
Customized
Power supply :
Low voltage rail power
Operation type :
Safe low voltage rail powered
Description
kpd-60 tons electric transfer trolley, motorized transfer trolley manufacturers for working line

1. Product Introduce

BEFANBY kpd-60 tons electric transfer trolley, motorized transfer trolley manufacturers for working line is powered by low voltage electricity from railways, the kind of transfer trolley is one of the most convenient material handling equipment and it often can be widely used in the industry field an so on. Of course,compared other transfer trolley,it main features as it follows,its rails is isulated with the ground, and its wheels are isulated with the ground, so doesn't others.it is the advantage that the tracks trolley have, why we design is that its convenient (only rails needed) and its simple operation.

About BEFANBY, Our company have professional team and utilize more advanced technique to design and develope it , and it has been a long year to manufacture it attentively. Simutaneously, it will be more easy and flexible.Simple structure and low cost make it popular for workshop transportation.

Please contact us if you's like to learn more details and get the quotation.

BEFANBY have over 16 years' experience in the material handling fields.

2. Working Principle of kpd-60 tons electric transfer trolley, motorized transfer trolley manufacturers for working line

BEFANBY KPD-60 tons electric transfer trolley, motorized transfer trolley manufacturers for working line, the power source AC380v is transformed into AC36v two-phase and are respectively connected to the two rails.Then the flat carts' wheels conduct the AC36v on rail into the electrical appliance box at the bottom of the carts, And then the AC36v is transformed into DC36v and then control the DC motor through the DC control system to make the flat carts start, stop, go forward and backward railways.

3. Feature of kpd-60 tons electric transfer trolley, motorized transfer trolley manufacturers for working line

1. Anti-high temperature

2. Safe devices are installed(alarm light, dead man stop, e-stop, lamp, bumper, etc)

3. Customization can be supported

4. If required large load capacity, dual drive can be installed, and the largest capacity can reach to 500T

5. China manufacturing

6. Apply to various occasions

7. safety, flexibility, stable start, big starting torque, small capacity to the gear gearing

8. Low voltage, long lifetime

9. The running distance is not limited.

10. When the running distance is more than 70m, it is better to increase the transformers to make up for the voltage which as been lowed.

11. The transfer trolley can be used in turning occasions, suach as "S“ "C" arc-shaped rail, etc.

4. Technique Parameter of kpd electric transfer trolley, motorized transfer trolley manufacturers for working line
Model KPD-2t KPD-5t KPD-10t KPD-16t KPD-20t KPD-25t KPD-30t KPD-40t KPD-50t KPD-63t
Rated load 2 5 10 16 20 25 30 40 50 63
Table size Length(L) 2000 3500 3600 4000 4000 4500 4500 5000 5500 5600
Width(W) 1500 2000 2000 2000 2200 2200 2200 2500 2500 2500
Height(H) 450 450 500 500 550 600 600 650 650 750
Wheel Base 1200 2500 2600 2800 2800 3200 3200 3800 4200 4300
Rail Inner Gauage 1200 1435 1435 1435 1435 1435 1435 1435 1435 1435
Wheel Diameter 270 300 300 350 350 400 400 500 500 600
Wheel Quantity 4 4 4 4 4 4 4 4 4 4
Ground Clearance 50 50 50 50 50 50 50 50 50 75
Running Speed 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20 0-20 0-20
Motor Power 1 1.2 1.6 2 2.2 3 3.5 4 5 6.3
Transformer Power 3 5 5 6.8 6.8 6.8 10 10 10 20
Transformer Quatity 1 1 1 1 1 1 1 1 1 1
Running Distance 80 80 80 80 80 80 80 60 50 50
Max Wheel Load 14.4 25.8 42.6 64.5 77.7 94.5 110.4 142.8 174 221.4
Reference Weight 2.8 3.6 4.2 5.5 5.9 6.5 6.8 7.6 8 10.8
Recommended Rail Model P15 P18 P18 P24 P24 P38 P38 P43 P43 P50
6.Brief Introduction----BEFANBY
Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a collection of research, design, manufacture, installation and after-sales service of electric handling bogie ,transfer carts as one of the professional manufacturing company, which has a modernized management team and excellent staff.And our prodcuts gets CE, SASO,SGS,ISO certificate and other 8 national patent, our products have been exported to more than 60 countries and regions,such as Saudi Arabia, UAE, Malaysia, Singapore, Singapore, Australia, Canada, Mexico, Germany, etc.

BEFANBY CERTIFICATION
7. How to choose suitable transfer trolley?
All of our transfer trolleys can be customized as client's requirement, for choose the most suitable and economic transfer trolley,please kindly providing the following information:
  • Transfer or handling what material/cargo?
  • What capacity do you need?
  • This trasnfer trolley is running on rails or ground(floor)?
  • Your requirment for table size:length,width and height?
  • How about the running distance?
  • How many working hours in per day?
