Specifications
Brand Name :
Bochuangshikong
Model Number :
BCSK-GD001
Certification :
CE CCC FC
Place of Origin :
shenzhen
MOQ :
1
Price :
USD 3888
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, Western Union, MoneyGram
Supply Ability :
22222
Delivery Time :
5-10
power :
190W
Power Supply :
AC110V-240V
Interference distance :
1000-2000M
Description

Fixed UAV jammer 1500m all day automatic drive off forced landing return UAV reaction equipment anti UAV jammer

Dear friends, Shenzhen Bochuang spatiotemporal Communication Technology Co., Ltd. is a

professional jammer manufacturer, focusing on mobile phone signal jammer, GPS jammer, UAV

anti-jamming equipment, signal detector, detection system and other security equipment. If

you need to contact or inquire, please email us 1369199493@qq.com , official website

www.szbcsk.com Tel: 86013798491049

Outdoor Waterproof Anti Drone System for 24 hour 7 day

This anti drone system can force the drone land slowly or return home immediately when the drone intrudes in the 1000 meter
radius of protection area.

Operation
* 3 pressing buttons to control on/off of GPS WIFI2.4G 5.8G
* Control on/off at computer

Feature
* High gain fiberglass antenna and strong power push jamming RF amplifier
* Coverage 360° round circle of 500-1000 meter radius
* IP65 waterproof, heat resistant, anti shock, thunder protection
* Smart cooling system design to ensure it is at low temperature and long time stable work

Side View Back View



Specification

Product Name: fixed UAV reaction equipment jammer
Brand and model: bcsk-gd001 of Bochuang spacetime brand
Drone Jammer
Jamming Frequency 2.4G: 2400-2500MHz 100W
2.4G: 2400-2500MHz 30W
5.8G: 5725-5850MHz 30W
GPS : 1560-1620MHz (Optional) 30W
Protection Area 500-1000 meter radius,depends on real environment
Work Time 24 hours 7 days continuously
Water&Dust Proof Level IP65 level
Out shell Material Die Cast Aluminum Alloy
Product Size 50*45*25cm
Product Weight 29kg (not including antenna)
Output Power 190 W
Power consumption 360 W
Power supply AC Adapter 110-220V/DC 15A
Working temperature -20 ° ~ +75 °
Relative humidity 10~95%
Installation Wall Mount or Pole Holding
Suggest Installation Height 3-15m
High Gain Directional Antenna
Dimensions*mm 620*350*220mm
(Height/Width/Depth)
Package Size Φ32*600mm
Antenna weight(kg) 0.39Kg
Frequency Range Type A: 2400-2500MHz
Type B: 5725-5850MHz
Type C: 1560-1620MHz
Gain 3-5dBi
VSWR ≤1.5
Polarization Vertical
Horizontal Beam-width(0º) 360º
Vertical Beam-width(0º) 25±3º
Ovality (dB) ≤±2dB
Front-to-back ratio(dB) ≥25
Input Impedance(Ω) 50Ω
Maximum input power(W) 100W
Input connector type N/M
Lightning Protection DC Ground
Rated Wind Velocity(m/s) 60m/s
Operational Humidity(%) 10- 95
Ra-dome Color Gray Color
Ra-dome material UPVC
Operating temperature(ºC) -30~70 º
Installation Method Pole Mount
Mounting hardware(mm) ¢40~¢80
Mechanical tilt(º) 0-10º


Application
Protect these areas from drone enter and interruption:
> Government: Prison, Military, Police, Border Control, Government Buildings, Detention Centre, Drug rehabilitation centers, Other Law enforcement
> Critical Infrastructure: Chemical Industry,Oil Depot,Oil Refinery, Gas Station Power generate plants,Nuclear power plants,Water control center, Reservoir
> Mass Event: Sports Stadium&Events, Important Meetings, Entertainment Performance
> Museums, Campus,Theatre,Church,Hospital
> Scientific research center,Security Service,Test Facilities
