BCX 1070Nm Square Tube Laser Cutting Machine For Stainless Steel
BCX 1070Nm Square Tube Laser Cutting Machine For Stainless Steel
BCX 1070Nm Square Tube Laser Cutting Machine For Stainless Steel
BCX 1070Nm Square Tube Laser Cutting Machine For Stainless Steel
BCX 1070Nm Square Tube Laser Cutting Machine For Stainless Steel
BCX 1070Nm Square Tube Laser Cutting Machine For Stainless Steel
BCX 1070Nm Square Tube Laser Cutting Machine For Stainless Steel
BCX 1070Nm Square Tube Laser Cutting Machine For Stainless Steel
BCX 1070Nm Square Tube Laser Cutting Machine For Stainless Steel
BCX 1070Nm Square Tube Laser Cutting Machine For Stainless Steel
BCX 1070Nm Square Tube Laser Cutting Machine For Stainless Steel
BCX 1070Nm Square Tube Laser Cutting Machine For Stainless Steel
Specifications
Brand Name :
bcx
Model Number :
bcx—0005
Certification :
ce
Place of Origin :
China
MOQ :
1
Price :
1500US dollars
Payment Terms :
T/T
Supply Ability :
99
Delivery Time :
8
Packaging Details :
specialized shatterproof packing
Product name :
square tube laser cutting machine
Model :
bcx—0005
Brand :
bcx
Wavelength :
1070Nm
Working speed :
12 m/min
Description

round and square tube fiber laser cutting machine pipe cutting machine

Product Description

Machine Features:

* Stability and reliability of light path system and control system.

* Imported original fiber lasers,high and stable,lifespan is over 100000 hours.


* Higher cutting quality and efficiency,cutting speed is up to 60 m/min.


* High performance german reducer,gear and rack;Japanese guide and ball screw.

* We machine is equipped Automatic fix rotary axis, it more convenient for customer

Model
TL-3015 fiber laser cutting machine
Working Area
1500*3000mm(optional:1300*2500mm/2000*4000mm/2000*6000mm)
Laser source
Raycus laser source(optional:IPG/MAX)
Laser Power
750W/1000W/ 1500W/ 2000W/3000W (10-100%)
Laser cutting heads
Raytools auto focus cutting head
Rotary axis
Automatic fix rotary axis
Control system
Cypcut control system
Laser Wavelength
1070Nm
Working Speed
12 m/min
Max speed
60 m/min
Laser power injection
2,5 kw
X Y position accuracy
±0,015mm
X Y Reposition accuracy
±0,015mm
Min. cutting line width
0,02mm
Working Voltage
380 V± 10% / 50Hz
Auxiliary gas
N2/ O2
Motor
Japan sevro motor
Material
stainless steel, carbon steel , titanium sheet , and so on
Weight
3500kg

BCX 1070Nm Square Tube Laser Cutting Machine For Stainless SteelBCX 1070Nm Square Tube Laser Cutting Machine For Stainless Steel
