BLE 5.0 1Mbps Bluetooth Low Energy Location Beacon KC Approved
BLE 5.0 1Mbps Bluetooth Low Energy Location Beacon KC Approved
BLE 5.0 1Mbps Bluetooth Low Energy Location Beacon KC Approved
BLE 5.0 1Mbps Bluetooth Low Energy Location Beacon KC Approved
BLE 5.0 1Mbps Bluetooth Low Energy Location Beacon KC Approved
BLE 5.0 1Mbps Bluetooth Low Energy Location Beacon KC Approved
BLE 5.0 1Mbps Bluetooth Low Energy Location Beacon KC Approved
BLE 5.0 1Mbps Bluetooth Low Energy Location Beacon KC Approved
BLE 5.0 1Mbps Bluetooth Low Energy Location Beacon KC Approved
BLE 5.0 1Mbps Bluetooth Low Energy Location Beacon KC Approved
Specifications
Brand Name :
Createk
Model Number :
ITBB803-EPA
Certification :
CE, RoHS, FCC, KC
Place of Origin :
China
MOQ :
36 pcs / negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100k pcs/ month
Delivery Time :
9 weeks
Price :
USD9.9 / negotiable
Packaging Details :
Carton
Bluetooth :
4.2/5.0
Chipset :
3431
App :
Yes, Createk APP for setting
Distance :
80 meters
Dimension :
53.86*24.93 mm
Working Temp :
-40℃~85℃
Battery :
ER14250 2*1200 mAh 5 years
Waterproof :
IP67
Acceleration sensor :
Yes
Description

Bluetooth Beacon with New chip 3431 broadcast UUID, Major Minor reach 80 meters with ear IP67 acceleration sensor

Model Name: ITBB803-EPA

Bluetooth beacon ITBB803_hanging ear type_3431_waterproof_acceleration

Product Overview

This beacon use a China chipset vendor product, our experienced r&d engineer has passed all the test and design from china bluetooth chipset and verified the performance and quality based on this chipset. it proved the beacon has same level quality as Nordic chipset, and in current situation Nordic chipset still will have big shortage and in high price level, so it's good news that we can replace it with china chipset and will provide to our clients best quality product with lower price and stable supply.

. Bluetooth beacon based on low power Bluetooth chip

. Powered by two ER14250 batteries and can be used for up to 5 years

. Broadcast UUID, Major, Minor, RSSI, battery power, Bluetooth name, Bluetooth MAC address

. Beacon parameters can be set through the mobile phone APP

. Broadcast distance can reach 80 meters

. Using 3M glue can be easily installed and fixed

. Firmware have connect type and non-connect type

. With temperature and humidity sensor and acceleration sensor optional

. With unique design for IP67 protection

. CE, RoHS, FCC, KC compliance

. With acceleration sensor

Specification:

Hardware Parameters

Hardware parameters
Antenna PCB Antenna
Battery ER14250 2*1200mAh
Voltage 3.6V
Dimensions (D×H) 53.86*24.93mm
Wireless Performance
Wireless standard Bluetooth ® 4.2
Frequency range 2400MHz---2483.5MHz
Data rate 1Mbps
Modulation mode GFSK Modulation
Encryption AES HW Encryption
Transmission power Tx Power -20 to +4 dBm in 4 dB Steps
Reveiving sensitivity -93dBm at 1 Mbps BLE
Work mode Peripheral
Other

Environment

 Working temperature: -40℃~85℃
Storage temperature: -40℃~85℃
Working humidity: 10%~90% Non-condensing
Storage humidity: 5%~90% Non-condensing

Temperature and humidity indicators(for Bluetooth beacons with temperature and humidity sensors)
Measurement accuracy of humidity ±1.5 %RH
Humidity measurement resolution 0.01 %RH
Temperature measurement accuracy ±0.1 ℃ (20℃-60℃)
Temperature measurement resolution 0.015 ℃
Temperature measurement range -40~125 ℃
