Mechanical Steel Plate Bending Machine , Hydraulic Steel Sheet Rolling Machine
Mechanical Steel Plate Bending Machine , Hydraulic Steel Sheet Rolling Machine
Mechanical Steel Plate Bending Machine , Hydraulic Steel Sheet Rolling Machine
Mechanical Steel Plate Bending Machine , Hydraulic Steel Sheet Rolling Machine
Specifications
Brand Name :
Friendship Machinery
Model Number :
FSM-PB
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Supply Ability :
30 sets per month
Delivery Time :
20 working days
Packaging Details :
wooden pallet
Maximum thickness of plate :
16mm
Maximum width of plate :
3000mm
Yielding limit sheet metal :
245º
Loaded with minimum coil diameter :
Φ800mm
Bending roll speed :
4m/min
Two bottomroller center distance :
430mm
Description

1. Technical parameter

No. Item Unit Value
1 Maximum thickness of plate mm 16
2 Maximum width of plate mm 3000
3 Yielding limit sheet metal º 245
4 Loaded with minimum coil diameter mm Φ800
5 Bending roll speed m/min 4
6 Two bottomroller center distance mm 430
7 Upper roller diameter mm 340
8 Bottom roller diameter mm 260
9 Motor power KW 18.5

2. Description of structure

The machine adopts 3-roller symmetrical structure with the upper roller moving vertically in the center between the two lower rollers, which is achieved through the drive of the screw, the nut, the worm and the lead screw, the two lower rollers, and provides the plate materials with torque through the engagement of the output gear of the moderator with the fear of the lower rollers. The machine is the overall structure, the working section and the main transmission section are all installed on a rigid welding base. It is convenient to installation and adjustment.
