High Strength CNC Hydraulic Press Brake Machine 3 Phase 380V / 50hz
High Strength CNC Hydraulic Press Brake Machine 3 Phase 380V / 50hz
High Strength CNC Hydraulic Press Brake Machine 3 Phase 380V / 50hz
High Strength CNC Hydraulic Press Brake Machine 3 Phase 380V / 50hz
High Strength CNC Hydraulic Press Brake Machine 3 Phase 380V / 50hz
High Strength CNC Hydraulic Press Brake Machine 3 Phase 380V / 50hz
Specifications
Brand Name :
Friendship Machinery
Model Number :
QC11Y
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Supply Ability :
10 sets per month
Delivery Time :
30 working days
Packaging Details :
Standard export packing
Model :
WX67Y
Control type :
NC
Driven method :
Hydraulic
Description

1. Technical parameters

Model Units WC67Y-200T/3200
Controller / E21
The bended steel sheet strength N/mm2 450
Nominal pressure kN 2000
Worktable length mm 3200
The distance between uprights mm 2520
Throat depth mm 400
Ram stroke mm 200
Max opening height between worktable and ram mm 480
Gear pump Model / CP1-40-P-10R
Flow L/min 40
Pressure Mpa 31.5
Ram speed Unloaded mm/s 60
Work mm/s 8
Return mm/s 70
Working Pressure of hydraulic system Mpa 26
Main motor Power kW 15
Electrical system V/Hz 3 phase,380/50
Net Weight kg 11500
Overall dimension mm 3100x1800x2850

High Strength CNC Hydraulic Press Brake Machine 3 Phase 380V / 50hz

High Strength CNC Hydraulic Press Brake Machine 3 Phase 380V / 50hz
