Safety Hydraulic Shearing Machine Hydraulic Iron Worker Punch And Shear Machine
Safety Hydraulic Shearing Machine Hydraulic Iron Worker Punch And Shear Machine
Safety Hydraulic Shearing Machine Hydraulic Iron Worker Punch And Shear Machine
Safety Hydraulic Shearing Machine Hydraulic Iron Worker Punch And Shear Machine
Safety Hydraulic Shearing Machine Hydraulic Iron Worker Punch And Shear Machine
Safety Hydraulic Shearing Machine Hydraulic Iron Worker Punch And Shear Machine
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
Q35Y
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Price :
USD12000
Name :
Double-cylinder hydraulic punch & shear machine
Cutting angle :
7 / 8 degree
Ram stroke :
80
Number of strokes :
8 / 6
Description

1. Introduction

● Double-cylinder hydraulic punch & shear machine

● Five independent stations for punching, shearing, notching, cutting and bending

● Large punching table with multi-purpose bolster

● Rear notching station, Low power inching and adjustable stroke at punching station

● Centralised pressure lubrication system

● Electric panel with overload protection elements and integrated controls

● Safety movable foot pedal

2. Accessories List

● A set of hole punching die

● A set of angle steel blade

● A set of square and round bar blade

● A set of shearing plate blade

● A set of notching blade

3. Tecnical parameter

Specification Unit Q35Y-16 Q35Y-20 Q35Y-25 Q35Y-30
Pressure Ton 55 75 110 140
Max.cutting tickness Mm16 16 20 25 30
Plate strength n/mm2 <450 <450 <45 <45
Cutting angle degree 7 8 8 8
Shearing size of one stroke mm 16*250, 8*400 20*330, 10*480 25*300, 16*600 30*355, 20*600
Ram stroke mm 80 80 80 80
Number of strokes cpm 8 8 6 8
Throat thickness mm 300 355 400 600
Pumching thickness mm 16 20 25 26
Max.Puching diameter mm 25 30 35 38
Power of main motor Km 4 5.5 7.5 11
Over al dimensions(L*W*H) Mm 1640*730*1770 1860*800*1900 2355*960*2090 2680*1040*2330
Weight of machine Kg 1600 2000 4800 6800
