Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
FSM
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Delivery Time :
30 working days
Packaging Details :
Wooden box
Welding method :
TIG
Work-piece :
tube to tube
Welder system :
germany brand
Cooling tank :
Include
protective gas :
Argon
Main features :
All position welding
Description

Automatic Orbital Tube Welding Machine For Pipe Engineering

Tube Butt Welding Machine

1. Introduction

Automatic orbital tube welding machine is orbital weld heads for fusion (GTAW) welding of fittings, tubing and thin wall pipe. Ideal solution for welds in the food & dairy, pharmaceuticals, biotechnology, chemical, semiconductor industry and in all applications where space is very limited.

Besides particularly suitable for welding all common micro fittings. Welds materials such as stainless steel, titanium, hastelloy and other auto weldable alloys. During weld process, it is without wire feeding but with argon protection and tungsten insert (TIG) welding.

2. Tube information

- Suitable tube diameter: Φ19.05mm-Φ76.2mm

- Tube thickness: 0.8-2.5mm

- Material: carbon steel, SS steel, titanium, titanium alloy

- Welding part of Tube center min rotating radius 72.5mm, min straight part length can be clamped is 25mm

3. System configuration

No.

Equipment name and model

Q'ty

 Unit Remark
1

GTW200 digital tube to tube welding source with recycling water tank

 1 Set 5A-200A
2

GTS40 tube to tube automatic TIG welding head

 1 Set Φ19.05mm-Φ76.2mm
3

Alu package box (power source)

 1 Unit -
4

Alu package box (welding head)

 1 unit -
5

Gas input pipe

 1 unit -
6

Manual and tool box

 1 set -

Automatic Pipe Welding Machine Tube Fit Pipe Engineering , Butt Welding Machine

Welding pool is effected by different forces as picture, gravity, surface tension, arc spraying force, only gravity direction the same in different position, other two force directions always change, so welding parameter has to be set in several areas to meet welding requirements.
