Orbital Tube To Tube Welding Machine , Tube To Tube Orbital Welding Machine
Orbital Tube To Tube Welding Machine , Tube To Tube Orbital Welding Machine
Orbital Tube To Tube Welding Machine , Tube To Tube Orbital Welding Machine
Orbital Tube To Tube Welding Machine , Tube To Tube Orbital Welding Machine
Orbital Tube To Tube Welding Machine , Tube To Tube Orbital Welding Machine
Orbital Tube To Tube Welding Machine , Tube To Tube Orbital Welding Machine
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
FSM
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Delivery Time :
30 working days
Packaging Details :
Wooden box
Welding method :
TIG
Work-piece :
tube to tube
Welder system :
germany brand
Cooling tank :
Include
protective gas :
Argon
Main features :
All position welding
Description

Orbital Tube To Tube Welding Machine

Tube to Tube Orbital Welding Machine

Model: GTS40

1. Tube information

- Suitable tube diameter: Φ6.35mm-Φ38.1mm

- Tube thickness: 0.8-2.5mm

- Material: carbon steel, SS steel, titanium, titanium alloy

- Welding part of Tube center min rotating radius 72.5mm, min straight part length can be clamped is 25mm

2. All position welding

Welding pool is effected by different forces as picture, gravity, surface tension, arc spraying force, only gravity direction the same in different position, other two force directions always change, so welding parameter has to be set in several areas to meet welding requirements.

3. Welder introduction

- Simple and direct parameter interface, timely show welding condition

- Adopt Germany Siemens PLC and Germany EWM machine core, make sure machine reliability

- 220V single phase power supply, inside switch power modular supply power; ensure outer power wave within 20% to guarantee welding seam repetitiveness

- Auto programming function, not rely on too much on skilled operator

- Adjust freely remote or nearby control, easy operation

- One key printing, auto printing function

- Auto reset function

- Parameter password protection function

Orbital Tube To Tube Welding Machine , Tube To Tube Orbital Welding Machine
