QC11Y-16x8000 Hydraulic Guillotine Shearing Machine For Q235A Steel Sheet
QC11Y-16x8000 Hydraulic Guillotine Shearing Machine For Q235A Steel Sheet
QC11Y-16x8000 Hydraulic Guillotine Shearing Machine For Q235A Steel Sheet
QC11Y-16x8000 Hydraulic Guillotine Shearing Machine For Q235A Steel Sheet
QC11Y-16x8000 Hydraulic Guillotine Shearing Machine For Q235A Steel Sheet
QC11Y-16x8000 Hydraulic Guillotine Shearing Machine For Q235A Steel Sheet
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
QC11Y
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
10 sets per month
Delivery Time :
30 days
Packaging Details :
standard export package
Steel sheet material :
Q235A
COntroller :
E21S
Steel sheet strength :
450N.M
Seals ring :
Valqua, Japan
Mold material :
T8
Electric components :
Schneider or Siemens
Description

QC11Y-16*8000 NC guillotine shearing machine

1. Technical parameters

Model Unit QC11Y-16×8000
The maximum shear thickness mm 16
The maximum shear width mm 8000
The sheared steel sheet strength N/mm2 450
Shearing angle ° 0.5-2.5
The strokes min-1 6-15
The blade length mm 8100
The distance between uprights mm 8230
The back gauge range mm 20-1000
Main motor power KW 45
Gear pump Model / 80
Flow ml/r

63

.
Pressure Mpa 31.5
Net weight kg 50000
Overall dimension mm 9100×2600×3000

2. The device structure and character

● This device main used to cut mild carbon steel sheet with the thickness range from 4mm to 16mm, and the width less than 8000mm, when the steel strength not more than 450N/mm2. So if want to use the device to cut the plate sheet with the higher strength more than 450N/mm2, the cut thickness will be thin than normal.

● Adopts integrated hydraulic system, with good reliability.

● Adopts three points roll guides, to release clearance between guides, higher cut quality.

● Back gauge used intelligence display installation, auto count shear number, back gauge can

adjustable by client’s requirement.

● Installed a hand wheel on the front of device, rotate it to adjust cutting edge clearance, client

should to adjust it by different thickness.

● Up blade adopter adopts falling-in type, easy to blank, and can to higher cut accuracy.

● With the performance to section cut.

● Electric controller system: EC21S.
