WC67Y 160T / 3200 Hydraulic Sheet Metal Brake For Plate / Press Brake For Hydraulic Press
WC67Y 160T / 3200 Hydraulic Sheet Metal Brake For Plate / Press Brake For Hydraulic Press
WC67Y 160T / 3200 Hydraulic Sheet Metal Brake For Plate / Press Brake For Hydraulic Press
WC67Y 160T / 3200 Hydraulic Sheet Metal Brake For Plate / Press Brake For Hydraulic Press
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
WC67Y
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Delivery Time :
10 working days
Packaging Details :
Wooden box
Bending method :
Manual or Pneumatic
Molds :
Two pcs
Foot switch :
Include
Work-piece :
Steel or Aluminum
Package :
wooden box
Color :
Red
Description

WC67Y 160T / 3200 Hydraulic Sheet Metal Brake For Plate / Press Brake For Hydraulic Press

1. Technical parameters

Model Units WC67Y-160T/3200
The bended steel sheet strength N/mm2 450
Nominal pressure kN 1600
Worktable length mm 3200
The distance between uprights mm 2520
Throat depth mm 400
Ram stroke mm 200
Max opening height mm 470
Gear pump Model / CP0-25-P-10R
Flow L/min 25
Pressure MPa 31.5
Ram speed Unloaded mm/s 60
Work mm/s 8
Return mm/s 70
Working pressure of hydraulic system Mpa 26
Main motor power kW 11

2. The main features of E21 numerical control device

● E21 press brake numerical control device from Estun automation co., ltd.

● Positioning control of back gauge.

● Intelligent positioning control.

● One-side and two-side positioning which Eliminates spindle clearance effectively.

● Retract functions.

● Automatic reference searching.

● One-key parameter backup and restore.

● Fast position indexing.

● 40 programs storage space, each program has 25 steps.

3. Using environment

● The work voltage is 380V/ 50HZ/ 3P, the wave value ±10%.

● The environment temperature is 0℃-40℃, relative humidity: 20-80%, less ash, without harmful and corrosive gas, far away strong shock source and electromagnetic disturbance.

WC67Y 160T / 3200 Hydraulic Sheet Metal Brake For Plate / Press Brake For Hydraulic Press
