NC Hydraulic Shearing Machine , Guillotine Type Steel Plate Shearing Machine
NC Hydraulic Shearing Machine , Guillotine Type Steel Plate Shearing Machine
NC Hydraulic Shearing Machine , Guillotine Type Steel Plate Shearing Machine
NC Hydraulic Shearing Machine , Guillotine Type Steel Plate Shearing Machine
NC Hydraulic Shearing Machine , Guillotine Type Steel Plate Shearing Machine
NC Hydraulic Shearing Machine , Guillotine Type Steel Plate Shearing Machine
NC Hydraulic Shearing Machine , Guillotine Type Steel Plate Shearing Machine
NC Hydraulic Shearing Machine , Guillotine Type Steel Plate Shearing Machine
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
QC11Y
Certification :
CE, ISO
Place of Origin :
CHIA
MOQ :
1
Supply Ability :
5-10 sets per month
Delivery Time :
30 working days
Packaging Details :
Standard pakcing
NC system :
E21S
Blade material :
6CrW2Si
Main motor :
Jiangsu Hengli
Main electric components :
Siemens or Schneider
Seals :
VALQUA, Japan
Hydraulic pump :
HIGH-TECH
Description

NC Hydraulic Shearing Machine , Guillotine Type Steel Plate Shearing Machine

1. Technical parameters

Model Unit QC11Y-16×3200
Maximum shearing thickness mm 16
Maximum shearing width mm 3200
Sheared steel sheet strength N/mm2 450
Shearing angle ° 0.5-2.5
Strokes min-1 12-20
Blade length mm 3300
Distance between uprights mm 3430
Back gauge range mm 20-800
Main motor power KW 22
Gear pump Model / CP1-50-P-10R
Flow ml/r 50
Pressure Mpa 31.5

2. The device structure and character

● This device main used to cut mild carbon steel sheet with the thickness range from 3mm to 16mm, and the width less than 3200mm, when the steel strength not more than 450N/mm2. So if want to use the device to cut the plate sheet with the higher strength more than 450N/mm2, the cut thickness will be thin than normal.

● Adopts integrated hydraulic system, with good reliability.

● Adopts three points roll guides, to release clearance between guides, higher cut quality.

● Back gauge used intelligence display installation, auto count shear number, back gauge can adjustable by client’s requirement.

● Installed a hand wheel on the front of device, rotate it to adjust cutting edge clearance, client should to adjust it by different thickness.

NC Hydraulic Shearing Machine , Guillotine Type Steel Plate Shearing Machine

NC Hydraulic Shearing Machine , Guillotine Type Steel Plate Shearing Machine
