3200mm Swing Type Hydraulic Sheet Cutting Machine , NC Steel Plate Shearing Machine
3200mm Swing Type Hydraulic Sheet Cutting Machine , NC Steel Plate Shearing Machine
3200mm Swing Type Hydraulic Sheet Cutting Machine , NC Steel Plate Shearing Machine
3200mm Swing Type Hydraulic Sheet Cutting Machine , NC Steel Plate Shearing Machine
3200mm Swing Type Hydraulic Sheet Cutting Machine , NC Steel Plate Shearing Machine
3200mm Swing Type Hydraulic Sheet Cutting Machine , NC Steel Plate Shearing Machine
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
QC12Y
Certification :
CE, ISO
Place of Origin :
CHIA
MOQ :
1
Supply Ability :
5-10 sets per month
Delivery Time :
30 working days
Packaging Details :
Standard pakcing
NC system :
E21S
Blade material :
6CrW2Si
Main motor :
Jiangsu Hengli
Main electric components :
Siemens or Schneider
Seals :
VALQUA, Japan
Hydraulic pump :
HIGH-TECH
Description

3200mm Swing Type Hydraulic Sheet Cutting Machine , NC Steel Plate Shearing Machine

1. Overview
● Knife shelf adopt step-less adjustment , permit micro adjustment with mechanical back gauge device, digital display movement of back gauge and shear time.
● Controller: E21S controller specialized used in cutting machine.

2. Technical parameters

Model Unit QC12Y-8x3200
Controller / E21S
Maximum shear thickness mm 8
Maximum shear width mm 3200
Shearing angle ° 1.5
Times of strokes per/mm 11
Blade length mm 3300
Distance between vertical columns mm 3420
Back gauge range mm 20-600
Work table height mm 725
Main motor power kW 11

Axial plunger pump

 Model / 20MCY14-1B
Flow ml/r

20

.
Pressure Mpa 31.5


3. The device structure and character
● Blade part: with indicator to display cutting-edge gap adjustable value, the adjustment is simple and quick; logical display the shearing numbers.
● Workbench part: works pace install fence type safety protection device.

3200mm Swing Type Hydraulic Sheet Cutting Machine , NC Steel Plate Shearing Machine

NC CONTROL SYSTEM: E21S


3200mm Swing Type Hydraulic Sheet Cutting Machine , NC Steel Plate Shearing Machine

FEET SWITCH
