Metal Plate Hydraulic Guillotine Shearing Machine QC11Y Shearing For Plate Cutting
Metal Plate Hydraulic Guillotine Shearing Machine QC11Y Shearing For Plate Cutting
Metal Plate Hydraulic Guillotine Shearing Machine QC11Y Shearing For Plate Cutting
Metal Plate Hydraulic Guillotine Shearing Machine QC11Y Shearing For Plate Cutting
Metal Plate Hydraulic Guillotine Shearing Machine QC11Y Shearing For Plate Cutting
Metal Plate Hydraulic Guillotine Shearing Machine QC11Y Shearing For Plate Cutting
Metal Plate Hydraulic Guillotine Shearing Machine QC11Y Shearing For Plate Cutting
Metal Plate Hydraulic Guillotine Shearing Machine QC11Y Shearing For Plate Cutting
Specifications
Brand Name :
FRIENDSHIP MACHIENRY
Model Number :
QC11Y
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
10 sets per month
Delivery Time :
30-40 days
Packaging Details :
standard export packing
Model :
QC11Y
Control way :
NC
System :
E21 Brand
Foot switch :
Include
Main motor :
Siemens
Shearing thickness :
19mm
Description

Technical parameters

Model Unit QC11Y-16×9000
Maximum shear thickness mm 16
Maximum shear width mm 9000
Sheared steel sheet strength N/mm2 450
Shearing angle ° 0.5-2.5
Strokes min-1 5-15
Blade length mm 9100
Distance between uprights mm 9230
Back gauge range mm 20-1000
Main motor power KW 55
Gear pump Model / CP2-125-P-10R
Flow ml/r 125
Pressure Mpa 31.5
Net weight kg 57000
Dimension mm 10100*3000*3800

The device structure and character

● This device main used to cut mild carbon steel sheet with the thickness range from 4mm to 16mm, and the width less than 9000mm, when the steel strength not more than 450N/mm2. So if want to use the device to cut the plate sheet with the higher strength more than 450N/mm2, the cut thickness will be thin than normal.

● Adopts three points roll guides, to release clearance between guides, higher cut quality.

● Back gauge used intelligence display installation, auto count shear number, back gauge can

adjustable by client’s requirement.

Metal Plate Hydraulic Guillotine Shearing Machine QC11Y Shearing For Plate Cutting

Metal Plate Hydraulic Guillotine Shearing Machine QC11Y Shearing For Plate Cutting

E21 NC system
