Gantry type street pole welding machine for wind tower production line
Gantry type street pole welding machine for wind tower production line
Gantry type street pole welding machine for wind tower production line
Gantry type street pole welding machine for wind tower production line
Gantry type street pole welding machine for wind tower production line
Gantry type street pole welding machine for wind tower production line
Specifications
Brand Name :
FSM
Model Number :
WS24
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
20 sets per month
Delivery Time :
30 working days
Work-piece material :
Q235A
Welder :
OTC
Control method :
CNC
Software :
FastCAM
Description

1. Technical parameter

No. Item Specification
1 Machine width 3000mm
2 Rail length 15000mm
3 Diameter of high mast 300-1800mm
4 Length of high mast 12000mm
5 Welding wire diameter 3.2-5mm
6 Welding wire speed 250-1200mm/min
7 Power 10KW (excluding welder power)
8 Dimension 2830*4450*3695mm

2. Supply range

● Travel motor: YDS100-4 low speed motor

● Lifting motor: SCWS-08 deceleration machine

● Flux recycle system: flux recovery machine, power bucket, pipe

● Submerged arc welder: MZ1000

● Welding ground wire 140mm2: 32m

● Welding arm: arc guide device, welding gun

● 7 sets cable movement pulley, 10# I beam (15m), 24kg rail (15m * 2)

● Control panel, electric box

Gantry type street pole welding machine for wind tower production line

Gantry type street pole welding machine for wind tower production line

Product tags

single pole welding machine

,

pole welding machine

,

multi-spot welding machine
