Hydraulic CNC Press Brake And Shearing Machine For Steel Plate
Hydraulic CNC Press Brake And Shearing Machine For Steel Plate
Hydraulic CNC Press Brake And Shearing Machine For Steel Plate
Hydraulic CNC Press Brake And Shearing Machine For Steel Plate
Hydraulic CNC Press Brake And Shearing Machine For Steel Plate
Hydraulic CNC Press Brake And Shearing Machine For Steel Plate
Specifications
Brand Name :
Friendship Machinery
Model Number :
FSM-PB
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Supply Ability :
30 sets per month
Delivery Time :
20 working days
Packaging Details :
wooden pallet
Model :
WE67K
The maximum shear thickness :
10mm
Controller :
DA52 Or DA66T
The sheared steel sheet strength :
450N/mm2
Shearing angle :
0.5-3°
The strokes :
7min-1
Description

Hydraulic CNC Press Brake and Shearing Machine for Steel Plate, Press brake Machine

1. Overview

● The device adopts all steel-welded construction, and vibratory stress relief. Thus the device with good rigidity and high strength, to permit high accuracy.

● The whole frame with good rigidity, work is stable, safety and reliable, easy to operate.

● To adopt stress theory to control the deformation of structural parts effectively, so can to get satisfied work-piece.

● The workbench adopts bottom cylinder to do deflection compensation, to higher work accuracy.

● Controller: E21 from ESTUN is a CNC controller specialized in torsion axis synchronous press brake machine.

2. Technical parameters

Model Units 160T/3200 500T/8000
Maximum thickness of plate mm 8 8
Nominal pressure KN 1600 5000
Length of the worktable mm 3200 8200
The distance between uprights mm 2400 6000
Throat depth mm 320 450
Ram stroke mm 160 300
Maximum opening height mm 420 520
Ram speed Work speed mm/s 120 50
Press mm/s 8.5 7.5
Return mm/s 90 60
Main motor power KW 11 45
Net weight kg 10200 65000
Overall dimension mm 3300*1600*2700 8100*2500*4000

Hydraulic CNC Press Brake And Shearing Machine For Steel Plate

CNC control system from DELEM
