Specifications
MOQ :
1 set
Packaging Details :
Standard package
Delivery Time :
30 working days after down payment
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
PHJ
Certification :
CE, ISO
Place of Origin :
CHINA
Machien name :
H beam production line
Beam size :
800*1500mm
Thickness :
6-32mm
Welding way :
SAW welding
Welding technology :
Single arc single wire
Warantee :
14 monthes
Description

Automatic H Beam Production Line

H Beam Assembling Welding Straightening Machine

H beam 3 in 1 machine

H beam combination machine

Double H-beam assembling, welding and straightening machine production line is composed by 2 sets of H-beam assembling, welding and straightening machines, driving roller conveyor, idler roller conveyor, driving elevating roller conveyor, flange centering device, 90° overturning machine, overturning machine with magnetic sucker, conveying chain moving device.

2 sets of H-beam assembling, welding and straightening machines are laid in parallel staggered. The first machine will assemble one flange plate and one web plate to T beam, second machine will add another flange plate to this T beam, then assembled to H-beam.

  • Web height: 200-1500mm
  • Web thickness: 6-14mm
  • Flange width: 150-800mm
  • Flange thickness: 6-20mm
  • Workpiece length: 4000-12000mm
  • Assembling and welding speed: 0.3-3m/min
  • Main machine power: 4 kW×2 = 8 kW
  • Roller conveyor power: 0.55×14 = 7.7 kW
  • Conveying chain moving motor power: 3 kW
  • Flux recycling power: 3 kW×4 = 12 kW
  • Hydraulic station power: 5.5 kW×4 = 11 kW
  • Overturning hydraulic station power: 5.5 kW×2 = 11 kW
