Specifications
Brand Name :
Friendship Machinery
Model Number :
FSM Series
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Supply Ability :
20 sets per month
Delivery Time :
25 working days
Packaging Details :
standard packing
Description

Portable CW3200D Car Painting Room With Rieelo Disel Burner G20

Booth Dimensions

- Internal Size(LxBxH)

15000x5000x5000 mm

- External Size(LxBxH)

16800x5160x5900 mm

Foundation and Floor

- Loading Capacity of Galvanized Grating

NO

- Surface Area

20M²(Rear air exhust plenum chamber )

- Metal Basement

NO

- Drive-in Ramps

NO

Wall and Door

- Steel Wall and Roof Panel

Double Construction with Insulations EPS 60mm

- Thickness

Double Construction , with Insulations EPS 50mm

- Folded Entrance Door With Safety

Glass Window

4300x4800 mm(BxH)

- Operator’s Door With Safety , Glass

Window

800x2000 mm(BxH) 2PCS

Lighting

- Ceiling Lightings

16 Units, each 4x36 W, Total 2304W

- Side Lightings

24 Units, each 2x36 W, Total 1728W

- Brightness

>1000 Lux, IP54 Grade

Filtration

- Prefilters

Fiberglass,Paint-Stop-Filters Plate type duel filters

- Ceiling Filters

EU5 Fine Filters, 6 Units

- Floor Filters

Fiberglass, Paint-Stop-Filters

Ventilation System

- Direct Drive Motor (Fresh Air)

1x7.5KW,970RPM,380V,50HZ motor certification:CE

- Direct Drive Motor (Exhaust Air)

1x7.5KW,970RPM,380V,50HZ Domestic motor certification:CE

- Fan Capacity

25000m³/h

- Air Flow Speed

+/- 0.28 m/sin an empty booth

Heating System

- Heating Exchanger

Stainless Steel 1Gr18Ni9Ti

- Heating Exchange Capacity

1x232KW(260.000kcal/H)RIELLO

- Max. Drying Temperature

80 ℃

- Heating time

10-15 min (from 20 to 60℃) by Drying Phase

- Heating Type (on option)

Diesel / Gas Burner

Control Board

- Control system

Stander control Delta Depressurization start system

- Function

Spraying ,baking, warming spray paint, emergency stop switch

- PLC

yes

- Inverter control

On option

- Import element

master device import element

- Overpressure Manometer

yes

- Alarm equipment

yes

Portable CW3200D Car Painting Room With Rieelo Disel Burner G20
