Marine Steel Wire Crane Convenient For Shipyard Welding Machine
Marine Steel Wire Crane Convenient For Shipyard Welding Machine
Marine Steel Wire Crane Convenient For Shipyard Welding Machine
Marine Steel Wire Crane Convenient For Shipyard Welding Machine
Marine Steel Wire Crane Convenient For Shipyard Welding Machine
Marine Steel Wire Crane Convenient For Shipyard Welding Machine
Marine Steel Wire Crane Convenient For Shipyard Welding Machine
Marine Steel Wire Crane Convenient For Shipyard Welding Machine
Specifications
Brand Name :
Friendship Machinery
Model Number :
FSM Series
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Delivery Time :
30 working days
Packaging Details :
Standard export packing
Description

Marine Steel Wire Crane Convenient For Shipyard Welding Machine

The steel wire amplitude cargo crane, with landing working condition as design basis, is specially designed for various cargo ships.


The crane can be installed in the middle of ships or bow sides.


The crane adopts wire cable amplitude variation, planetary reducer lift winch, and rotation driving mechanism, and has reliable operation, durability, convenient maintenance and other characteristics.

1. The crane can be equipped with:


- Cab air-conditioning system
- Grab system
- Suspension arm projection lamp
- Touch screen display function
- Foldable Boom CraneCCS, DNV,ABS,GL,LR,BV,RINA,NK,KR and other classification societies

2. The specific specifications can be designed according to customer demands:

Crane
type

SWL
(t)

Working radius

Jib angle
RL/CL
(Deg)

Load×speed
(t×m/min)

Luffing time
RL/CL
(s)

Slewing speed
(r/min)

/

/

MAX (m)

MIN (m)

/

/

/

/

HX25-22C

25

22

4

250/00

25×20
5×40
Or 25×20
10×30

50/90

0.8

HX25-26C

25

26

4.5

250/00

/

63/120

0.6

HX25-30C

25

30

5

250/00

/

63/120

0.6

HX30-22C

30

22

4

250/00

30×20
6×40
Or 30×20
12×30

50/90

0.8

HX30-26C

30

26

4.5

250/00

/

63/120

0.6

HX30-30C

30

30

5

250/00

/

63/120

0.6

HX35-22C

35

22

4.5

250/00

35×15
7×30
Or 35×15
14×20

63/120

0.6

HX35-26C

35

26

5

250/00

/

80/150

0.5

HX35-30C

35

30

5.5

250/00

/

80/150

0.5

HX40-22C

40

22

4.5

250/00

40×12
8×24
Or 40×12
16×18

63/120

0.5

HX40-26C

40

26

5

250/00

/

80/150

0.4

HX40-30C

40

30

5.5

250/00

/

80/150

0.4

HX50-22C

50

22

4.5

250/00

50×10
10×20
Or 50×10
20×15

80/150

0.4

HX50-26C

50

26

5

250/00

/

100/180

0.3

HX50-30C

50

30

5.5

250/00

/

100/180

0.3

Marine Steel Wire Crane Convenient For Shipyard Welding Machine
