Motorized Pipe Welding Turning Rolls , Cylinder Shell Tank Welding Rotator
Motorized Pipe Welding Turning Rolls , Cylinder Shell Tank Welding Rotator
Motorized Pipe Welding Turning Rolls , Cylinder Shell Tank Welding Rotator
Motorized Pipe Welding Turning Rolls , Cylinder Shell Tank Welding Rotator
Motorized Pipe Welding Turning Rolls , Cylinder Shell Tank Welding Rotator
Motorized Pipe Welding Turning Rolls , Cylinder Shell Tank Welding Rotator
Motorized Pipe Welding Turning Rolls , Cylinder Shell Tank Welding Rotator
Motorized Pipe Welding Turning Rolls , Cylinder Shell Tank Welding Rotator
Specifications
Brand Name :
Friendship Machinery
Model Number :
PR Series
Certification :
CE, BV
Place of Origin :
CHINA
MOQ :
1 set
Packaging Details :
Steel framework and wire mesh
Supply Ability :
30 sets per month
Description

Motorized Pipe Welding Turning Rolls , Cylinder Shell Tank Welding Rotator

1. Introduction


Pipe welding rotator (lifting welding turn roller) is specially designed and manufactured

for purpose of meeting the requirements of enhancing productivity, increasing the extent of

automatic, reducing welder’s working intensity and adapting to piping workshop prefabrication.

The welding head will be relatively fixed, while the piping spool piece revolving at a specific

rate, and the high efficient and low cost shielded welding or SAW process is adopted, so it has the

features of easy-operation, reliable-performance and wide-application field.


2. Application

Used to weld, polish and assemble the cylinder-shells, and to line the shells with rubber.

3. Specification

Model

Pipe diameter

Maximum loading

Motor

Wheel speed

Column elevating

Overall dimension

PR0.5

50-350mm

0.5ton

0.37kw

0.1-1m/min

Manual

1260*500*410mm

PR1

50-426mm

1ton

0.55kw

1260*500*410mm

PR5

50-630mm

5ton

1.3kw

Motorized

1900*1500*700mm

PR10

100-1000mm

10ton

1.6kw

2240*1510*800mm

4. Option

● Polyurethane wheelor Rubber wheel or steel wheel ,
● Anti-creep function,
● Hydraulic lifting for fit up pipe,
● Hydraulic tilting function ,
● Automatic traveling or Manual traveling on the rail,
● Customization.


5. Advantage

We can make all kinds of rollers according different customers different requests. Maximum

loading capacity can reach to 2000tons, self-aligned or adjustable roller beds/ turning rolls.
