Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
GS SERIES
Certification :
CE, ISO
Place of Origin :
CHINA
DIameter :
16-40mm
Motor :
4KW
Voltage :
380V/ 50HZ
Warranty :
1 year
Speed :
60rpm
Machine name :
Steel bar threading machine
Description

32mm Steel Rebar Threading Machine

Steel Bar Threading Machine

Steel Straight Thread Screw Rolling machine

CNC Drilling Machine

Bolt Threading Machine

1. Introduction

Rebar paralleling threading machine is designed for processing steel bar, it is including main framework, clamp, slider, cycloid reducer, feeding device, limited device, control system.

2. Features

● Change blade only cost 5 mins

● Threading will be finished in 30 secons and easy to operate

● 45# high steel after welded with a high precision

● Meet JGJI07-96 A standard

3. Specification

No. Item Parameter
1 Rebar diameter 16-40mm
2 Moor 4KW
3 Voltage 380V, 50HZ
4 Main axle rotation speed 40-62rpm
5 Maximum threading length 80mm
6 Weight 560kgs

4. Connect sleeve & couples information list

Model O.D. (mm) L (mm) Thread pitch (mm) Thread angle (°) N.W. (kg) EXW Price (USD)
Φ16 24 40 2.5 75 0.08 0.2
Φ18 27 45 2.5 75 0.09 0.27
Φ20 31 50 2.5 75 0.18 0.38
Φ22 33 55 2.5 75 0.20 0.43
Φ25 37 60 3.0 75 0.28 0.55
Φ28 41 65 3.0 75 0.35 0.68
Φ32 47 70 3.0 75 0.5 1.02
Φ36 53 85 3.0 75 0.8 1.70
Φ40 59 90 3.0 75 1.0 2.32
