Shipbuilding Steel Butt Longitudinal Seam Welding Machine 10 - 35mm Plate
Shipbuilding Steel Butt Longitudinal Seam Welding Machine 10 - 35mm Plate
Shipbuilding Steel Butt Longitudinal Seam Welding Machine 10 - 35mm Plate
Shipbuilding Steel Butt Longitudinal Seam Welding Machine 10 - 35mm Plate
Shipbuilding Steel Butt Longitudinal Seam Welding Machine 10 - 35mm Plate
Shipbuilding Steel Butt Longitudinal Seam Welding Machine 10 - 35mm Plate
Specifications
Brand Name :
Friendship Machinery
Model Number :
FSM Series
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Delivery Time :
30 working days
Packaging Details :
Standard export packing
Description

Shipbuilding Steel Butt Longitudinal Seam Welding Machine 10 - 35mm Plate

1. Product Detail

The machine use three arc three wire four power submerged arc welding mode, welding type is single-side double-side forming, this machine is mainly composed of main door frame, welding trolley, torch up and down lifting device, welding torch left and right horizontal moving device, submerged arc tracking device, upper flux recycle device, welding parameter memory (controller), electromagnetic platform device, copper gasket device, flux spreading clean trolley, bottom flux recycle device, submerged arc welding system and so on.


2. Technical parameter

Welding way

Three arc three wire four power submerged

arc welding

Welding method

Single-side double-side forming

Plate thickness

10-35mm

Welding length

4000-25000mm

Welding current&voltage control type

Centralized control

Welding seam track way

Auto-electronic tracking

Welding speed

200-900mm/min

Flux spreading recycle way

Auto-spreading recycle

Plate material

A, B, D steel and AH32, AH36, DH32, DH36 steel for ship

Welding seam distance between adjacent two sets

2mm

Shipbuilding Steel Butt Longitudinal Seam Welding Machine 10 - 35mm PlateShipbuilding Steel Butt Longitudinal Seam Welding Machine 10 - 35mm Plate

Main structure showing
