60mm H Beam Production Line Hydraulic Straightening Machine 18.5kw
60mm H Beam Production Line Hydraulic Straightening Machine 18.5kw
60mm H Beam Production Line Hydraulic Straightening Machine 18.5kw
60mm H Beam Production Line Hydraulic Straightening Machine 18.5kw
60mm H Beam Production Line Hydraulic Straightening Machine 18.5kw
60mm H Beam Production Line Hydraulic Straightening Machine 18.5kw
Specifications
Brand Name :
Friendship Machinery
Model Number :
HYJ-60 Series
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 set
Price :
USD33,000
Delivery Time :
30 working days after down payment
Packaging Details :
Standard package
Description

60mm H Beam Production Line Hydraulic Straightening Machine 18.5kw

1. Major technical Parameters

● Width of the flange: 200-800mm
● Thickness of the flange: 20-60mm
● Minimum height of the web: 350mm
● Drive motor: 18.5kw
● Maximum output torque: 34770N.m
● Linear velocity of the work piece: 7.496m/min
● Hydraulic pressure system: 11kw
● Output volume of the oil pump: 25m1/r
● Maximum system pressure: 25Mpa
● Normal working pressure: 20Mpa


2. Provide goods and compose parts


● Main frame of correcting machine: base, left-and-right frame, motor, deceleration machine, guide wheel, up roll, press roll
● Conveyor: base, 14m roller way and so on
● Electric control: electric control box
● Spare parts: switch*2, wrench*1


3. Performance


H beam flange hydraulic straighteningmachine is used for the calibrate the flange of H beam. Through the lever principle and elastic recovery, it bends the flange of the I beam or H beam when the beam passing through the hole.


The equipment is made up of electric motor, reductor, driving wheel correcting device, initiative hoist cylinder, former, mainframe, stand, hydraulic system, front/back elevating roller rack of pendulum type and the electric control system. The correcting mechanism is compact, solid and easy to operate.


4. Technical files


● Using manual of the machine (Include electrical schematic)
● Shipping list
● The certification of the machine
● The basis of drawing of the machine
