H Beam Shot Blasting Machine Industrial For Car Spray Booth
H Beam Shot Blasting Machine Industrial For Car Spray Booth
H Beam Shot Blasting Machine Industrial For Car Spray Booth
H Beam Shot Blasting Machine Industrial For Car Spray Booth
H Beam Shot Blasting Machine Industrial For Car Spray Booth
H Beam Shot Blasting Machine Industrial For Car Spray Booth
Specifications
Brand Name :
Friendship Machinery
Model Number :
FSM Series
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Supply Ability :
20 sets per month
Delivery Time :
25 working days
Packaging Details :
standard packing
Description

H Beam Shot Blasting Machine Industrial For Car Spray Booth

Outside Size

7100x5630x3810 (LxWxH)

Inside Size:

7000x4000x2800 (LxWxH)

Foundation and Floor

Loading Capacity of Galvanized

Grating

650KG/ wheel

Surface Area

27M²(Full Galvanized Grating gills )

Metal Basement

350mm Height

Drive-in Ramps

3Units,each 1050 mm

Wall and Door

Steel Wall and Roof Panel

Double Construction with Insulations

rock wool 50mm

Thickness

Double Construction with Insulations

rock wool 50mm

3-Folded Entrance Door With Safety

Glass Window

3200x2700 mm(BxH)

Operator’s Door With Safety ,Glass

Window

800x2000 mm (BxH),With door closer

Lighting

Ceiling Lightings

8 Units, each 4x36 W, Total 1152W

Side Lightings

8 Units, each 2x36 W, Total 576W

Brightness

>1200 Lux, IP54 Grade

Filtration

Prefilters

G3 Grade,Pockets, 4 Units

Ceiling Filters

EU5 Fine Filters, 6 Units

Floor Filters

Fiberglass, Paint-Stop-Filters

Exhaust Fan Filters

Fiberglass, Paint-Stop-Filters With

intake air pipe

Ventilation System

Direct Drive Motor (Fresh Air)

1x7.5KW,970RPM,380V,50HZ Motor

certification:CE

Direct Drive Motor (Exhaust Air)

1x5.5KW, 970RPM, 380V,50HZ Motor

certification:CE

Fan Capacity

25.000m³/h

Air Flow Speed

+/- 0.25 m/s in an empty booth

Heating System

Heating Exchanger

Stainless Steel 1Gr18Ni9Ti

Heating Exchange Capacity

186KW(260.000Kcal/H)

Max. Drying Temperature:

80 ℃,

Heating time:

5-7 min (from 20 to 60ºС)by Drying Phase

Heating Type (on option)

Diesel Burner RG5D(260.000Kcal/H)

RIELLO, with two rangers

Control Board

Control system

IC MCU Control system

Function

Spraying,baking, warming spray paint,

emergency

stop switch

PLC

No

Industrial &Network Computing

( touch screen)

No

Inverter control

No

Overpressure Manometer

No

Alarm equipment

Yes,display on the electric cabinet

Fittings hanging slippage system

No

H Beam Shot Blasting Machine Industrial For Car Spray Booth

H Beam Shot Blasting Machine Industrial For Car Spray Booth
