CNC Plasma Cutting Machine For Sheet And Pipe , Pipe Profile Plasma Cutting Machine
CNC Plasma Cutting Machine For Sheet And Pipe , Pipe Profile Plasma Cutting Machine
CNC Plasma Cutting Machine For Sheet And Pipe , Pipe Profile Plasma Cutting Machine
CNC Plasma Cutting Machine For Sheet And Pipe , Pipe Profile Plasma Cutting Machine
CNC Plasma Cutting Machine For Sheet And Pipe , Pipe Profile Plasma Cutting Machine
CNC Plasma Cutting Machine For Sheet And Pipe , Pipe Profile Plasma Cutting Machine
Specifications
Brand Name :
Friendship Machinery
Model Number :
GS Series
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
10 sets
Supply Ability :
50 sets per month
Delivery Time :
30-40 working days
Packaging Details :
Export Standards
Panel thickness :
6-32mm
Products name :
CNC plasma cutting machine
Cutting size :
3000*6000mm (standard)
Plasma source :
Huayuan/ Hypertherm
Standard :
CE, ISO
CNC control :
Beijing Start or Shanghai Jiaoda
Description

CNC Plasma Cutting Machine for Sheet And Pipe

Pipe Profile Plasma Cutting Machine

Metal Plate CNC plasma cutting machine

Fiber laser cutting machine

Cnc Plate-Tube Plasma Cutting Equipment For Carbon Steel With Pipe Rotation Axis

1. Specifications

Cutting diameter range 60mm - 300mm
Flame cutting wall thickness 5mm - 50mm
The plasma cutting thickness depends on the size of the plasma power supply
Effective cutting length of the workpiece 3000mm
Cutting speed flame speed within 700mm / min ,The plasma cutting speed depends on the size of the plasma power supply
Pipe carrying weight ≤ 400KG
Moving speed 10mm / min - 4000mm / min
Movement axis X axis (transverse axis) Pipe rotation axis
Movement axis Y-axis (longitudinal axis) The torch moves horizontally along the pipe axis
Movement axis Z axis (torch lift shaft) Torch lifting shaft
Steel tube drive mode Electric drive chuck rotation to match the longitudinal equipment operation
Cutting method plasma cutting, flame cutting (depending on customer requirements)
Lifting mode Plasma (automatic arc pressure elevation) Flame (electric lift)
Cutting function selection intersecting line cutting / tube board one cut
Drive mode precision gearbox and gear drive
Drive motor Panasonic A5 drive / motor
Pipe diameter 0.1r / min - 25r / min
Reset accuracy ± 0.2mm
Cut the gun lift stroke 105mm
Chuck size 250mm


2. Samples

CNC Plasma Cutting Machine For Sheet And Pipe , Pipe Profile Plasma Cutting Machine

CNC Plasma Cutting Machine For Sheet And Pipe , Pipe Profile Plasma Cutting Machine
