Hanging Scaffold Wind Tower Production Line , Aluminum Steel Suspended Working Platform
Hanging Scaffold Wind Tower Production Line , Aluminum Steel Suspended Working Platform
Hanging Scaffold Wind Tower Production Line , Aluminum Steel Suspended Working Platform
Hanging Scaffold Wind Tower Production Line , Aluminum Steel Suspended Working Platform
Hanging Scaffold Wind Tower Production Line , Aluminum Steel Suspended Working Platform
Hanging Scaffold Wind Tower Production Line , Aluminum Steel Suspended Working Platform
Specifications
Brand Name :
Friendship Machinery
Model Number :
ZLP Series
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Delivery Time :
30 working days
Packaging Details :
Standard export packing
Description

Hanging Scaffold Wind Tower Production Line , Aluminum Steel Suspended Working Platform


It is designed particularly for heavy applications on facades, chimneys, silos, bridges etc.


The complete system consists of the working platform equipped with two electric LTD hoists and the support wheels, suspended by means of steel wire ropes from a suspension structure.

Hanging Scaffold Wind Tower Production Line , Aluminum Steel Suspended Working Platform

1. Safety systems


To ensure safe operation without danger to personnel, the platform is fitted with the following safety devices:
- Service brake incorporated in the LTD hoist.
- Two fall arrest devices (Anti-tilt LSF safety lock) acting on the safety wire ropes.
- Overload sensor incorporated in the LTD hoists according to EN 1808. (Option)
- Two upper limit switches.
- No power descent in case of power failure.
- Emergency stop.
- Phase controller. (Option)

2. The main para. Of ZLP1000 suspended platform


- Rated Load: 1000kg
- Lifting Speed: 8.7m/min
- Voltage-3Phase: 380V/ (415V/220V)
- Frequency: 50Hz/60Hz
- Power: 1.8kw×2
- Hoist: LTD100
- Safety Lock: LSF310
- Dia. of Wire Rope: 4×31SW+FC-10.2mm
- Platform Size: (2.5×3)×0.76×1.45m
- Weight of Suspension Jibs: 340kg
- Weight of Lifting Part: Aluminum340kg/Steel 520kg
- Counter Weight: 1200kg
- 20’ GPQty of Package: 8
- Technical Information

Hanging Scaffold Wind Tower Production Line , Aluminum Steel Suspended Working Platform
