Gantry CNC Plasma Cutting Machine For Steel Plate , CNC Flame Cutting Machine
Gantry CNC Plasma Cutting Machine For Steel Plate , CNC Flame Cutting Machine
Gantry CNC Plasma Cutting Machine For Steel Plate , CNC Flame Cutting Machine
Gantry CNC Plasma Cutting Machine For Steel Plate , CNC Flame Cutting Machine
Gantry CNC Plasma Cutting Machine For Steel Plate , CNC Flame Cutting Machine
Gantry CNC Plasma Cutting Machine For Steel Plate , CNC Flame Cutting Machine
Gantry CNC Plasma Cutting Machine For Steel Plate , CNC Flame Cutting Machine
Gantry CNC Plasma Cutting Machine For Steel Plate , CNC Flame Cutting Machine
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
GSD SERIES
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Delivery Time :
30 working days
Packaging Details :
Standard packing
Work-piece size :
3000*12000mm
Drilling thickness :
6-50mm for flame cutting
CNC system :
Beijing Start or Shanghai Jiaoda
Arc height controller :
HYD or Ontime, China
Servo motor :
Panasonic
Nesting software :
Beijing Starfire
Description

CNC plasma cutting machine, plasma cnc cutter

Cantilever cnc plasma cutting machine with one year warranty for metallic material

Model GSD-4000
Cutting mode Plasma Flame Flame and Plasma
Driving mode Servo motor or stepper motor, Dual-side
Cross beam width (m) 3m/3 .5m or customize
Effective working width (m) 1m less than track width
Guide rail Length (m) According to your cutting demands
Effective working length (m) 2m less than guide rail length
Flame cutting thickness (mm) 5-200 (specific type up to 300)
Plasma cutting thickness (mm) According to the plasma generator, common 1-30mm
Number of cutting torch At customers' requests
Cutting speed (mm/min) 50-8800
Running speed (mm/min) 12000
NC controller Beijing Start or Shanghai Jiaoda
Plasma power 100A, 120A, 200A, 300A ect . China or USA brand
Programming software China or Australia professional nesting software
Operation language English or Chinese or Russian


Machine body structure


1. Box weldment structure process tempering
2. Excellent rigidity and intensity.
3. Single drive adopts three-point fix structure.
4. Dura drive adopts symmetrical structure.

 Gantry CNC Plasma Cutting Machine For Steel Plate , CNC Flame Cutting Machine

Transmission


1. Rack and gear mesh transmission.
2. Gear box: SEW, high output torsion low noise.
3. Horizontal torch transmit by steel belt.
4. These devices are durable and long life device.

 Gantry CNC Plasma Cutting Machine For Steel Plate , CNC Flame Cutting Machine


Drive model

1. Japan AC servo motor
2. High stability of walking
3. Convenient maintenance

 Gantry CNC Plasma Cutting Machine For Steel Plate , CNC Flame Cutting Machine


Height controller

1. Torch carrier and torch
2. Torch carrier assembly including:
Motor, lifting device, torch, holder, gas valve, flashback arrester		 Gantry CNC Plasma Cutting Machine For Steel Plate , CNC Flame Cutting Machine

Gantry CNC Plasma Cutting Machine For Steel Plate , CNC Flame Cutting Machine
