Metal Steet Gantry Type CNC Plasma Cutting Machine , CNC Flame Plasma Cutting Machine
Metal Steet Gantry Type CNC Plasma Cutting Machine , CNC Flame Plasma Cutting Machine
Metal Steet Gantry Type CNC Plasma Cutting Machine , CNC Flame Plasma Cutting Machine
Metal Steet Gantry Type CNC Plasma Cutting Machine , CNC Flame Plasma Cutting Machine
Metal Steet Gantry Type CNC Plasma Cutting Machine , CNC Flame Plasma Cutting Machine
Metal Steet Gantry Type CNC Plasma Cutting Machine , CNC Flame Plasma Cutting Machine
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
GSD
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Delivery Time :
30 working days
Packaging Details :
Standard Packing
Control way :
CNC
Cutting method :
Plasma and Flame
CNC system :
Beijing Start or Shanghai Jiaoda
Plasma system :
Huayuan LGK200
Servo motor :
Panasonic, Japan
Warranty :
1 Year
Description

1. Main features

- Cross beam adopts steel structure, stable and durable.

- Trolley adopts cross-track structure, running smoothly and quickly.

- Transverse adopts splint type Φ25 bearing steel guide rail.

- Adopts 43KG heavy duty guide rail.

- Equip Honeybee CNC control system (15' colorful LCD display).or Hypertherm CNC control system.

- Support all kinds of plasma sources.

2. Specification

tem Parameters
Model 4000x8000x1CD+1A
Frame Construction Gantry, Dual Drive
CNC System HBCNC
Cutting Mode Both Oxy-fuel and Plasma
Plasma Power Source According to customer request
Plasma Cutting Material Mild steel, Stainless steel, Aluminum, Brass, etc.
Plasma Cutting thickness Depend on the plasma source
Oxy-fuel Cutting Gas Oxygen+Propane/ Acetylene
Oxy-fuel Cutting Thickness 6mm---200mm (mild steel only)
Track Span 4000 mm
Working Width 3100 mm
Guide Rail Length 8000mm
Working Length 6000mm
Bare Speed 12000mm/min
Cutting Speed 0~6000 mm/min(can regulate continuously)
Accuracy ±0.3mm
Working power AC 3 Phase, 380V
Frequency 50 HZ
