Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
FSM
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Delivery Time :
30 working days
Packaging Details :
Wooden box
Welding method :
TIG
Work-piece :
Tube to tube or Tube to tubeplate
Welder system :
Foreign brand
Cooling tank :
Include
Protective gas :
Argon gas
Main features :
All position welding
Description

Automatic Tube To Tube Panel Welding Machine

Pipe Engineering Orbital TubeWelding Machine

1. Tube information

- Suitable tube diameter: Φ31.8mm-Φ114.3mm

- Tube thickness: 0.8-2.5mm

- Material: carbon steel, SS steel, titanium, titanium alloy

- Welding part of Tube center min rotating radius 72.5mm, min straight part length can be clamped is 25mm

2. Requirements before welding

- Welding area 5-8mm has to polish, remove rust, till original metal color

- Pipe cutting has to flat, vertical, no burr, tube to tube no gap

- Clear the oil dirt by alcohol or acetone

- Workpiece has to manual argon tack welding, do not weld pipe to broken

3. Main parts supplier

No. Parts Maker
1 Welding power source German EWM
2 Control Siemens PLC
3 Touch screen Taiwan
4 Rotating drive KEYA
5 Water tank cooling pump Italian CEME
6 Welding head motor Switzerland MAXON

4. Welding torch information

Model GTS118
Rotating speed 0.194-3.877rpm
Gun code R 97
Welding protection gas Argon
Cooling way Water cooling
Cooling water flow ≥450ml/min
Maximum wall thickness 2.5 mm (Purity argon protection)
Welding tube diameter Φ31.8-Φ114.3mm
Weight 5kg
Maximum length 25mm
Maximum welding currency 120A Duty cycle: 40%
100A Duty cycle: 60%
80A Duty cycle: 100%
