Industry Orbital Tube Welding Machine , Spiral Duct Making And Forming Production Line
Industry Orbital Tube Welding Machine , Spiral Duct Making And Forming Production Line
Industry Orbital Tube Welding Machine , Spiral Duct Making And Forming Production Line
Industry Orbital Tube Welding Machine , Spiral Duct Making And Forming Production Line
Industry Orbital Tube Welding Machine , Spiral Duct Making And Forming Production Line
Industry Orbital Tube Welding Machine , Spiral Duct Making And Forming Production Line
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
FSM-FG
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
100 sets per month
Delivery Time :
10 working days
Packaging Details :
Wooden box
Diameter :
80-1500mm
Thickness :
0.4-1.2mm
Width of coil :
137mm or 140mm
Speed :
38m/min
Compressed air power :
0.7kmp
Material :
Galvanized steel or Stainless steel
Description

Description

- The module technique gives the customer the possibility to choosebetween a number of options, allowing him to create a machine a number of options, allowing him to create a machine for his specific needs.

- The frequency controlled main drive ensures a smooth acceleration and an almost noiseless operation.

- The outstanding patented flying slitter cuts the tubes to lengthwithout noise or hot sparks as known from the saws and provides smooth tube ends without deburring.

- The design and options fulfill the needs in HVAC to produce in mild steel, galvanized steel, stainless steel or aluminum

- The corrugation unit allows a reduction in material costs and makes the bigger diameter tubes more rigid.

Main Technical Specification

Diameter range 80-1600mm
Thickness of strip

0.4-1.3mm Glvanized steel

0.8mm Sinless steel

0.4-1.2mm Auminum
Strip width

standard 137mm up to 1mm

thickness, 140mm above. Other widths on request.
Lockseam Outside tube, on the inside on request.
Production speed Maximum 60 meters/min. depending on material
Cutting system The pqtented flying slitter
Net weight 2900kg
Gross weight 3200kg
Machine dimension 3000mm*1950mm*1700mm,
Package dimension 3050mm*2000mm*1800mm
Options Automatic length control system, controlled corrugation unit.METU flange slitter Saw blade cutter
