Trailer Beam Horizontal Welding Machine H Beam Production Line For Steel Construction
Trailer Beam Horizontal Welding Machine H Beam Production Line For Steel Construction
Trailer Beam Horizontal Welding Machine H Beam Production Line For Steel Construction
Trailer Beam Horizontal Welding Machine H Beam Production Line For Steel Construction
Trailer Beam Horizontal Welding Machine H Beam Production Line For Steel Construction
Trailer Beam Horizontal Welding Machine H Beam Production Line For Steel Construction
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
FSM
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
30 sets per month
Delivery Time :
30 working days
Packaging Details :
Standard packing
Welding width :
4000mm
Welding length :
15000mm
Voltage :
380V/ 50HZ
Warranty :
1 year
Control way :
PLC
Welder :
Lincoln DC1000
Description

Trailer Beam Horizontal Welding Machine

H Beam Production Line For Steel Construction

1. Features and introduction

● Gantry type trailer beam welding machine is designed for horizontal welding 2 seam, specially welding trailer beam less than 20°, it is the best solutions for semi-trailer production line.

● Main machine is adopt advanced frequency control technology, it is improved welding quality during the working processing.

● It adopts mechanical tracking technology to avoid repair welding for trailer beam, with a beautiful seam, high quality and the most importance is save cost.

● Single arc single wire welding to avoid burn out beam when welding thin plate

2. Technical parameter

No. Item Specification
1 Model FSM-HJ-15
2 Machine width 3750mm
3 Effective welding width 200-600mm
4 Rail length 16000mm
5 Effective welding length 14000mm
6 Welding speed 1500-2000mm/min

7

Trailer beam dimension

Web width: 200-600mm

Web thickness: 6-14mm

Flange height: 50-260mm

Flange thickness: 14-25mm

Trailer Beam Horizontal Welding Machine H Beam Production Line For Steel Construction
