Automatic Cnc Steel Plate Drilling Machine , H Beam Production Line Welding Beam
Automatic Cnc Steel Plate Drilling Machine , H Beam Production Line Welding Beam
Automatic Cnc Steel Plate Drilling Machine , H Beam Production Line Welding Beam
Automatic Cnc Steel Plate Drilling Machine , H Beam Production Line Welding Beam
Automatic Cnc Steel Plate Drilling Machine , H Beam Production Line Welding Beam
Automatic Cnc Steel Plate Drilling Machine , H Beam Production Line Welding Beam
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
FSM
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
30 sets per month
Delivery Time :
30 working days
Packaging Details :
Standard packing
Drilling diameter :
50mm
Drilling thickness :
80mm
Voltage :
380V/ 50HZ
Warranty :
1 year
Control way :
PLC
Working Size :
1000*1600mm
Description

Automatic CNC STeel Plate Drilling Machine

H Beam Production Line Welding Beam

● The maximum thickness of the work-piece: 80mm

● The maximum extension of the work-piece: 1000*1600mm

● The maximum diameter: 50mm

● Main drive rotating speed: 130-400r/min, step-less speed

● The maximum stoke of the main drive: 180mm (oil-cylinder feed)

● Oil-cylinder used for clamping working table: 12

● Pressed air: pressure 0.5Mpa, flow is 0.5M³/min (provided by user)

● Total power: 12KW

Turn on the power source, gas source and hydraulic station----input machining work-piece parameter----load and clamp work-piece, measure the height and the distance from the head----automatic machining begins (the driving force head moves to where it drills----the gantry frame clamps----the drilling head rotates and moves----using air to blow the dust and iron filings of where it drills----move to the setting place, change the drilling head’s speed for working speed, stop blowing and turn on the cooling system----after drilling a hole the drilling head should be back to the first place, turn off the cooling system and open the oil cylinder of the gantry frame----machining the nest hole)---stop the machine after machining all of the holes.

Automatic Cnc Steel Plate Drilling Machine , H Beam Production Line Welding Beam
