Profile Pull Bending Machine , Hydraulic Press Brake For Metal Sheet Plate
Profile Pull Bending Machine , Hydraulic Press Brake For Metal Sheet Plate
Profile Pull Bending Machine , Hydraulic Press Brake For Metal Sheet Plate
Profile Pull Bending Machine , Hydraulic Press Brake For Metal Sheet Plate
Profile Pull Bending Machine , Hydraulic Press Brake For Metal Sheet Plate
Profile Pull Bending Machine , Hydraulic Press Brake For Metal Sheet Plate
Profile Pull Bending Machine , Hydraulic Press Brake For Metal Sheet Plate
Profile Pull Bending Machine , Hydraulic Press Brake For Metal Sheet Plate
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
FSM
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
30 sets per month
Delivery Time :
30 working days
Packaging Details :
Standard packing
Capacity :
15tons
Motor :
5.5KW + 5.5KW
Voltage :
380V/ 50HZ
Warranty :
1 year
Control way :
PLC
Bending mould :
Option
Description

WXJY-10 CNC Pull Bending Machine

Profile Pull Bending Machine

Hydraulic Press Brake For Metal Sheet Plate

No. Item Specification
1 Maximum pulling capacity 15tons
2 Pull bending length 750-4000mm
3 Stretch cylinder stroke 760mm
4 Minimum pull bending radius 600mm
5 Mould seat height 350mm
6 Maximum section of clamp 150*150mm
7 Oil tank capacity 560L
8 Worktable height 750mm
9 Motor 5.5KW + 5.5KW
10 High oil pump model 10Mcy-14B * 2
11 Stretch position repeatability ±0.3mm
12 Big-arm cylinder forming speed 3 degree per second
13 Big-arm cylinder return speed 3 degree per second
14 Twin arm opening width 6800mm
15 Machine weight 16tons
16 Cooling method 7.5KW heat exchange
17 Mould worktable size 3200*1500mm
18 Mould install guide-rod 2 sets
19 Control method PLC
