C Z Interchangeable Purlin Roll Forming Machine , CZ Forming Machine Ceiling Machine
C Z Interchangeable Purlin Roll Forming Machine , CZ Forming Machine Ceiling Machine
C Z Interchangeable Purlin Roll Forming Machine , CZ Forming Machine Ceiling Machine
C Z Interchangeable Purlin Roll Forming Machine , CZ Forming Machine Ceiling Machine
C Z Interchangeable Purlin Roll Forming Machine , CZ Forming Machine Ceiling Machine
C Z Interchangeable Purlin Roll Forming Machine , CZ Forming Machine Ceiling Machine
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
FSM
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
30 sets per month
Delivery Time :
30 working days
Packaging Details :
Standard packing
Roller station :
22 units
Material :
Q195 or Q235
Voltage :
380V/ 50HZ
Warranty :
1 year
Forming speed :
20mm/min
Usage :
Ceiling/ column
Description

C Z Interchangeable Purlin Roll Forming Machine

CZ Forming Machine Ceiling Machine

● Product specification:

- C purlin width: 80-300mm

- Z purlin width: 120-300mm

- Flange: 35-80mm

- Edge:10-20mm

● Production capacity: high speed 25m/min (depends on punching work frequency)

● Material: 1.5-3.0mm, Q195 or Q235 hot-rolled black or galvanized steel strips

● Roller material: GCr15 bearing steel, after CNC lathe processing, make heat treatment up to HRC58-60 degree, then make high precision lathe processing and surface polished and chromed

● Main shaft material: 40Cr, after CNC lathe processing, make heat treatment up to HRC28-32 degree, then make high precision lathe processing and surface polished and chromed

C Z Interchangeable Purlin Roll Forming Machine , CZ Forming Machine Ceiling Machine

C Z Interchangeable Purlin Roll Forming Machine , CZ Forming Machine Ceiling Machine
