Anti - Explosion Type Industry Safety Cabinet , Walk In Storage Cabinets For Liquid
Anti - Explosion Type Industry Safety Cabinet , Walk In Storage Cabinets For Liquid
Anti - Explosion Type Industry Safety Cabinet , Walk In Storage Cabinets For Liquid
Anti - Explosion Type Industry Safety Cabinet , Walk In Storage Cabinets For Liquid
Anti - Explosion Type Industry Safety Cabinet , Walk In Storage Cabinets For Liquid
Anti - Explosion Type Industry Safety Cabinet , Walk In Storage Cabinets For Liquid
Anti - Explosion Type Industry Safety Cabinet , Walk In Storage Cabinets For Liquid
Anti - Explosion Type Industry Safety Cabinet , Walk In Storage Cabinets For Liquid
Specifications
Brand Name :
Friendship Machinery
Model Number :
BR
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
20 sets per month
Delivery Time :
25 working days
Packaging Details :
steel framework
Wall thickness :
50mm panel
Door type :
Double sides open
Framework structure :
Square steel tube
Insulation :
100mm height
Welding way :
Framework with full welding
Surface treatment :
PVC coating
Description

Outside walk-in storage cabinet

Model FSM-HW9000
Outside dimension 9000*2800*2300mm (W*D*H)
Inner dimension 8800*2600*2000mm (W*D*H)
Storage area 22.88m2
Warning labels Warning labels are easily to see in very dark situation or fire
Door type Double door design is meet international standard and Chinese fireproof request, with high quality fireproof tile to fill the distance between sheet to sheet, the thickness of door is 55mm and reach fireproof door standard. Double door size is 1950mm height and 2900mm width.
Door lock Germany GMT fireproof lock and closer, it will automatic close door once on fire
Weight 7000kgs

Framework structure

 Main framework with 9000mm square steel tube (200*100*5mm), column with square steel tube (100*100*5mm), bottom with 750mm galvanized steel tube (100*50*5mm) after welded for reinforce also four sides with U steel cross welded. Main framework has enough strength for lift and move.
Storage cabinet outside design Storage cabinet outside with integrated design (2.0mm galvanized steel), it has a good sealing and anti-rust effect
Fireproof and thermal insulation Double wall and fill in 100mm silicate fireproof rock wool board, play a good effect of fireproof/ thermal insulation, also has a beautiful appearance
Leakage tank Waste chemical storage cabinet has a leakage tank (200mm height), it can keep the clean of storage area, Also on the bottom of storage cabinet has a discharge valve, it used for discharge the liquid in the leakage tank. Steel grating is on the top of leakage tank, the loading capacity is 3000kgs/m2.

Anti - Explosion Type Industry Safety Cabinet , Walk In Storage Cabinets For Liquid

Anti - Explosion Type Industry Safety Cabinet , Walk In Storage Cabinets For Liquid

Temperature control type safety storage cabinet
