1500w Fiber Laser Cutting Machine , Hypertherm CNC Plasma Cutting Machine For Plate
1500w Fiber Laser Cutting Machine , Hypertherm CNC Plasma Cutting Machine For Plate
1500w Fiber Laser Cutting Machine , Hypertherm CNC Plasma Cutting Machine For Plate
1500w Fiber Laser Cutting Machine , Hypertherm CNC Plasma Cutting Machine For Plate
1500w Fiber Laser Cutting Machine , Hypertherm CNC Plasma Cutting Machine For Plate
1500w Fiber Laser Cutting Machine , Hypertherm CNC Plasma Cutting Machine For Plate
Specifications
Brand Name :
Friendship Machinery
Model Number :
GSJ
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
20 sets per month
Delivery Time :
25 working days
Packaging Details :
steel framework
Laser generator :
1500W Raycus
Cooling mode :
Water cooling
Control software :
Cypcut, China
Cutting head :
WSX or Raytools
Cutting type :
Fiber laser cutting
Cutting thickness :
0-25mm
Description

1. Technical parameter

Model Fiber laser cutting machine
Laser type Raycus-1500W
Laser wavelength 1080nm±5
Laser maximum power 1500W

Maximum cutting thickness

Carbon steel 14mm, Stainless steel 6mm, Brass 5mm
Total power consumption <10KW
Working size 3000*1500mm
Maximum cutting speed

0-80m/min (depending on the material and thickness)
X, Y, Z axis orientation precision ≤±0.05mm/m
X, Y, Z axis repeat precision ≤±0.03mm/m
Minimum line width ≤0.15mm
Maximum empty running speed 120m/min
Driving way Japanese YASKAWA servo motors system
Transmission way

Y-axis imported gear rack double driver, X-axis imported ball screw
Cooling system Water cooling
Continous working time 24 Hours
Environment temperature 0-35°C
Power requirements 220V/ 50Hz or 60Hz

2. Machine features

- Gantry dual drive, adopting advanced gear rack transmission structure. Equipped with grinding gear and rack, and through the precision collimator one time metering assembly. The machine will secure long-term high cutting speed, high precision transmission.

- The machine table machined by large planomiller, with high temperature annealing twice, and high strength complete welding, customer will have long-term payback.

- Applicable materials: stainless steel, carbon steel, alloy steel, spring steel, aluminum, silver, copper, titanium and some metal plate and pipe.

- Applicable industries: glasses, jewelry, kitchen ware, chassis and cabinet, metal pipe, lamp&lanterns, metal ware, hardware, precision machinery, auto parts, elevator, nameplate, advertisement, electronics, toys and other industries. metal fiber metal laser cutting machine for 1mm 2mm 3mm 5mm 6mm.
