Specifications
Brand Name :
Friendship Machinery
Model Number :
FG
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
20 sete per month
Delivery Time :
30 working days
Packaging Details :
wooden pallet, standard export package
Name :
Welding manipulator
Dimension :
2x2 - 10x10m
Thickness :
4-20mm
Warantee :
2 years
Origin :
Wuxi, China
Welding way :
Co2 welder or SAW welder
Description

Rotation Welding Manipulator For Tank Seam Welding

Welding Manipulator Positioner

1.The column beam adopts steel plate section structure, and the plane guide way is designed with good rigidity and low deflection of the structure.

2. crossbeam lifting adopts constant speed operation mode of AC motor, lifting smoothly and evenly.

3. measuring expansion adopts AC frequency conversion stepless speed regulation, constant torque output, smooth speed, guide rail for No. 45 steel, after welding to stress treatment, after planing, high strength, good stability, can guarantee long time non deformation.

4. cross beam expansion using rack and pinion drive, high transmission accuracy, smooth operation, speed, digital display and preset.

Products form Heavy duty Middle size Light duty Small size
Model DLH6070 DLH5060 DLH4050 DLH3040 DLH2030 DLH1015
Vertical elevation stroke 6000 mm 5000 mm 4000 mm 3000 mm 2000 mm 1000 mm
Boom retracting stroke 7000 mm 6000 mm 5000 mm 4000 mm 2000 mm 1000 mm
Frame rotation angle ±180° ±360°
Frame rotation speed 0.3 rpm Manual
Boom elevation speed 1 m/min 0.3 m/min
Boom feeding speed 0.12-1.2 m/min Manual
Trolley feeding speed 3 m/min Manual
Trolley rail span 2000 mm 1800 mm 1000 mm 800 mm
